Dongfeng tianlong 6*4 LHD 10tons-12tons telescopic crane boom mounted on truck for sale,Factory sale best price 10tons telescopic cargo truck with crane
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Dongfeng tianlong 6*4 LHD 10tons telescopic crane boom mounted on truck adopts dongfeng tianlong 6*4 LHD one row and a half driver cab, 5700+1350mm wheelbase, 7tons front axle/10tons double rear axles, 7 speed manual gearbox, 11.00R20 rail tires, Cummins 245hp/270hp diesel Euro 5 engine, etc.
More pictures of dongfeng tianlong 6*4 LHD 10tons truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
the specification of dongfeng 6*4 LHD 10tons telescopic truck with crane as below
| Product name |
Dongfeng 6*4 LHD 10tons telescopic crane boom mounted on truck for sale |
| Chassis type |
DFL1250A13 |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2500,2550×3760,3830 |
| Cargo body dimension (L*W*H)(mm) |
8400,8600×2350,2450×550,600,800 |
| GVW(kg) |
25000 (Kg) |
| Kerb Mass(kg) |
15400,16225 (Kg) |
| Rated mass(kg) |
9470,8645 (Kg) |
| Approach angle/ Departure angle(mm) |
18/11 (°) |
| Front suspension/rear suspension(mm) |
1500/3480, |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
ISD270 50; ISD245 50 |
| Displacement/Power(kw) |
6700ml/198(180)KW/270(245)hp |
| Manufacturer |
Dongfeng Cummins Engine Co.,Ltd |
| Chassis |
Drive Type |
6*4 |
| Wheelbase(mm) |
5700+1350 |
| Tread(front/rear) |
1965; 1880/1880 (mm) |
| Transmission |
7 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Dongfeng tianlong one and a half luxurious driver cab |
| Number of spring axle(front/rear) |
8/10 |
| Tire Type |
1100R20*6 |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8400,8600×2350,2450×550,600,800 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 10T 4sections knuckle crane boom |
| Crane boom lifting height |
15.5m |
| Crane boom working radius |
13.5m |
| Rotation |
Full hydraulic, full rotation |
| Aerial seat |
With aerial working seat to operate the truck |
| The color of the whole truck is upon request. |
