customized LIUQI brand 8*4 350hp diesel 16tons knuckle crane boom mounted on truck for sale, HOT SALE! cargo truck with crane
Truck mounted crane, also called crane truck, derrick lorry truck, a kind of vehicle by hydraulic lifting and stretching system to complete lifting, slewing, transporting by crane of the goods, always equipped on the cargo trucks, etc. The crane truck is made up of cargo truck chassis, cargo van, PTO, crane, etc. The chassis can choose Dongfeng, FAW, AUMAN, Steyr, etc.
Truck mounted crane can be sorted by different size: 2T truck mounted crane, 3.2Ttruck mounted crane, 4T truck mounted crane, 5T truck mounted crane, 6.3Ttruck mounted crane, 8T truck mounted crane, 10T truck mounted crane, 12T truck mounted crane, 16T truck mounted crane. Its arms could be retractable type of folding type. And can be designed to be two-section arms, three-section arms, and four-section arms.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Customized liuqi brand 8*4 LHD truck with crane, adopts liuqi brand H5 one row and a half driver cab, 2100+4350+1350mm wheelbase, 10 speed gearbox, 2*5.5T front axles, 11.00R20 rail tires, air conditioner, etc.
The cargo body dimension of Liuqi Brand 8*4 LHD truck with crane is 7800×2470,2450×550(mm);client choose to install China made CLW brand high quality 12tons-16tons knuckle crane boom, etc.
More picutres of LIUQI brand 16tons knuckle crane boom mounted on truck as below
specification of LIUQI brand 8*4 LHD 350hp diesel 16tons knuckle crane boom mounted on truck as below.
| Product name |
LIUQI brand 8*4 LHD 350hp diesel 16tons knuckle crane boom mounted on truck |
| Chassis type |
SX1181GP5 LZ1310M5FBT |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3780,3960 |
| Cargo body dimension (L*W*H)(mm) |
7800×2470,2450×550 |
| GVW(kg) |
31000(Kg) |
| Kerb Mass(kg) |
16160 (Kg) |
| Rated mass(kg) |
14710 (Kg) |
| Approach angle/ Departure angle(mm) |
19/11 (°) |
| Front suspension/rear suspension(mm) |
1512/2738 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6L350-50 |
| Displacement/Power(kw) |
8424ml/257KW/350hp |
| Manufacturer |
YUCHAI |
| Chassis |
Drive Type |
8*4 |
| Wheelbase(mm) |
2100+4350+1350, |
| Tread(front/rear) |
2080/2080; 1874/1874 (mm) |
| Transmission |
10 speed manual gearbox |
| Braking system |
Air braking |
| Cab |
LIUQI H7 one row and a half luxurious driver cab |
| Number of spring axle(front/rear) |
3/3/4 |
| Tire Type |
11.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
7800×2470,2450×550(mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install XCMG 16T 5sections knuckle crane boom |
| Lifting height |
15M |
| Working radius |
12M |
| The color of the whole truck is upon request. |
