best seller-dongfeng 4*2 LHD 180hp diesel Euro 5 8tons knuckle crane boom mounted on truck for sale,
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. More information, please feel free to contact with Ms. Anita. As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
This dongfeng brand 6.3tons folded truck with crane, adopts Dongfeng D913 one row and a half driver cab, 5100mm wheelbase, ISB190 50 Cummins diesel engine, fastgear 8 speed manual gearbox, 5tons front axle/10tons rear axle, 10.00R20 rail tires, 300 partial three layers boom, etc.
This dongfeng brand 8tons folded truck with crane is with the cargo body dimension(L*W*H): 6300*2294*550(mm), choose CLW Brand 6.3T folded crane boom.
Chengli Special Automobile Co.,ltd" --- the biggest special truck manufacture in China.
The main Brand Partner: DONGFENG, SINOTRUK, XCMG, IVECO, JAC, JMC, SHACMAN, Beiben, FAW, FOTON.
Driving Type: 4*2, 6*4, 8*4, 4*4, 6*6 , 4wd , off-road , 10 wheel , 12 wheeler , etc.
Capacity: 12m, 14m ,16m.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng 4*2 LHD 180hp diesel 8tons knuckle crane boom on cargo truck as below.
customized dongfeng brand 4*2 LHD yuchai 180hp diesel 8tons knuckle truck with crane with aerial working seat
the specification of dongfeng 4*2 LHD yuchai 180hp diesel 8tons knuckle crane boom mounted on truck as below.
| Product name |
Dongfeng 4*2 4*2 8tons folded crane boom mounted on truck for sale |
| Chassis type |
EQ1180GD5DJ |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2550×3800 |
| Cargo body dimension (L*W*H)(mm) |
5800×2500×550 |
| GVW(kg) |
18000 (Kg) |
| Kerb Mass(kg) |
11000 (Kg) |
| Rated mass(kg) |
6870 (Kg) |
| Approach angle/ Departure angle(mm) |
23/12 (°) |
| Front suspension/rear suspension(mm) |
1450/2450 |
| Fuel Type |
diesel |
| Max Speed |
110 |
| Engine |
Type |
YC6JA180-50 |
| Displacement/Power(kw) |
6870ml/140KW/180hp |
| Manufacturer |
Yuchai |
| Type |
6 cylinders -in-line inter-cooling diesel Euro 5 engine |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
5100 |
| Tread(front/rear) |
1810/1800 (mm) |
| Transmission |
Fastgear 8 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Dongfeng one and a half driver cab |
| Number of spring axle(front/rear) |
8/9+7 |
| Tire Type |
10.00R20 rail tires* 6+1 |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5800,4650×2500,2450×550 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 8T 4sections knuckle crane boom |
| Crane boom lifting height |
13m |
| Crane boom working radius |
9.75m |
| Rotation |
Full hydraulic, full rotation |
| Aerial seat |
With aerial working seat to operate the truck |
| The color of the whole truck is upon request. |
