HOT SALE! Best price DONGFENG 4*2 LHD 3.5tons telescopic crane boom mounted on truck for sale, smaller cargo truck with crane for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of dongfeng furuika brand 4*2 LHD 3.5tons telescopic crane boom mounted on truck as below.
Customized dongfeng 4*2 LHD diesel telescopic crane boom mounted on truck, adopts dongfeng single row driver cab, 3308mm wheelbase, yunnei 130hp diesel engine, 8 speed manual gearbox, 8tons rear axle, 825R16 rail tires, etc.
The dimension (L*W*H) of cargo body box is 3500*2300*600(mm), the overall dimension of dongfeng 3.5tons telescopic crane boom. Client chooses to install CLW brand 3.5tons telescopic crane.
The specification of DONGFENG 3.5tons telescopic crane boom mounted on truck as below.
| Product name |
Dongfeng brand 3.5tons telescopic crane boom mounted on truck for sale |
| Chassis type |
EQ1041SJ8BD2 |
| Parameters |
Overall dimension length/width/height (mm) |
5995×2400×2800,3470 |
| Cargo body dimension (L*W*H)(mm) |
3500×2300×550 |
| GVW(kg) |
4495(Kg) |
| Kerb Mass(kg) |
3250(Kg) |
| Rated mass(kg) |
1050(Kg) |
| Approach angle/ Departure angle(mm) |
20/15 (°) |
| Front suspension/rear suspension(mm) |
1130/1557 |
| Fuel Type |
diesel |
| Max Speed |
103 |
| Engine |
Type |
YN38CRE1 |
| Displacement/Power(kw) |
3760ml/95KW/130hp |
| Manufacturer |
Yunnei |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
3308 |
| Tread(front/rear) |
1769/1629 (mm) |
| Transmission |
8 speed |
| Braking system |
Air braking |
| Number of spring axle(front/rear) |
8/10+7 |
| Tire Type |
8.25R20 16PR * 6+1 |
| Air-condition |
Choose to install |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
3500*2300*600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 3.5tons 2/3/4 sections telescopic crane boom |
| Crane boom lifting height |
7.5m/9.5m/12m |
| Crane boom working radius |
5.5m/7.5m/10m |
| Rotation |
Full hydraulic, full rotation |
| The color of the whole truck is upon request. |
