Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
The truck-mounted crane is also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
Zhongqi Brand 1tons mini light duty truck with crane, adopts Zhongqi WANGPAI mini truck with crane truck chassis, 1650mm single row driver cab, 102hp gasoline Euro 5 engine, 5 speed gearbox, 3tons rear axle, 140mm boom, 185R14 vacuum tires*6, electronic power steering, front disk and rear drum, vacuum clutch, with ABS, etc.
Client choose 1tons 4 sections knuckle crane boom, the lifting radius is 4.2m; the lifting height is 5.6m; 200m remote control the truck with crane.
More pictures of mini 1tons truck with crane manufactured by Chengli Special Automobile Co.,Ltd. as below.
the specification of CLW Brand mini 1tons cargo truck with crane as below
Main technical parameters
|
| Truck model |
CLW5030JSQW5 mini truck with crane for sale |
| Suitable crane boom |
1T(1320kgs)
|
Crane boom brand |
HAOYI brand remote control/XCMG |
| Crane boom type |
Knuckle
|
Driver cab |
1650mm |
| Engine |
xinching 102hp |
gearbox |
5 speed transmission |
| Overall dimension(l*W*H) |
5.2×1.76×2.65m |
Total mass |
3.495t |
| Cargo body dimension(L*W*H) |
3.2×1.65×0.4m |
Curb mass |
1.92t |
| Truck frame |
140mm boom |
Tire type |
185R14LT 6PR*6 |
| Axle |
3t rear axle
|
Braking system |
Front disks and rear drum |
| wheelbase |
3050(mm) |
Seated person |
2
|
| displacement |
1495(ml) |
Max speed |
100(km/h) |
Main technical parameters of 1tons mini folded knuckle crane boom asbelow
| Item |
1tons knuckle crane boom |
| Max lifting mass(kg) |
1320 |
| Mini lifting mass(kg) |
380
|
| Max lifting moment (of force) |
1.7 T.m |
| Working radius (m) |
4.2 |
| Lifting height (m) |
5.6 |
| Crane mass(kg) |
150
|
| Outriggers span (mm) |
900
|
| Rotation degree |
330° rotation |
| System rated pressure |
18Mpa |
| Oil tanker volume |
10L |
