Isuzu Brand 4*2 LHD 6.3T telescopic crane boom mounted on truck for sale, HOT SALE! ISUZU truck with crane
Customized truck-mounted crane is also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
Chengli Special Automobile Co.,ltd" --- the biggest special truck manufacture in China.
The main Brand Partner: DONGFENG, SINOTRUK, XCMG, IVECO, JAC, JMC, SHACMAN, Beiben, FAW, FOTON.
Driving Type: 4*2, 6*4, 8*4, 4*4, 6*6 , 4wd , off-road , 10 wheel , 12 wheeler , etc.
Capacity: 12m, 14m ,16m.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Customized ISUZU FVR 240hp diesel 6.3tons telescopic crane boom mounted on truck adopts ISUZU brand FVR truck chassis, 5800mm wheelbase, ISUZU MLD 6 speed gearbox, 6.3tons front axle/13tons rear axle, 10.00-20 nylon tires, ISUZU FVR one row and a half luxurious reversible driver cab with power steering, air cut braking and air conditioner, etc.
The overall dimension(L*W*H) of ISUZU Brand truck with crane is 9000×2500×3470(mm); while the cargo body box dimension(L*W*H) is 5550×2300×600(mm). Clients choose to install CLW Brand 5tons/6.3tons telescopic/knuckle crane boom.
More pictures of ISUZU brand 6.3tons telescopic crane boom mounted on truck as below.
The specification of ISUZU brand 6.3tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
ISUZU Brand 4*2 LHD 6.3tons telescopic crane boom mounted on truck for sale |
| Chassis type |
QL5160XXYARFRY |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2500×3470 |
| Cargo body dimension (L*W*H)(mm) |
5550×2300×600 |
| GVW(kg) |
16000 (Kg) |
| Kerb Mass(kg) |
10550(Kg) |
| Rated mass(kg) |
5255(Kg) |
| Approach angle/ Departure angle(mm) |
26/10 (°) |
| Front suspension/rear suspension(mm) |
1335/1865 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
6HK1-TCNG40 |
| Displacement/Power(kw) |
7790ml/177KW/240hp |
| Manufacturer |
ISUZU |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
5800 |
| Tread(front/rear) |
1960/1855 (mm) |
| Transmission |
ISUZU MLD 6 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Isuzu FVR one row and a half luxurious driver cab |
| Number of spring axle(front/rear) |
9/7+7 |
| Tire Type |
10.00-20 16PR |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5550×2300×600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 5T/6.3T telescopic/knuckle crane boom |
| The color of the whole truck is upon request. |
