new best price Liuqi Brand 4*2 8tons knuckle crane boom mounted on truck for sale, hot sale! LIUQI 8tons knuckle truck with crane
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of LIUQI brand 8tons folded crane boom mounted on truck as below
High quality and beast price LIUQI brand 8tons folded crane boom mounted on truck for sale
HOT SALE! LIUQI brand 8tons knuckle crane boom mounted on truck
Customized liuqi LHD 8tons folded crane boom mounted on truck adopts liuqi truck chassis, 5100mm wheelbase, 8 speed gearbox, 5tons front axle/153 rear axles, 10.00R20 rail tires,etc.
The overall dimension(L*W*H) of liuqi Brand truck with crane is 9000×2550×3550,3780 (mm); while the cargo body box dimension(L*W*H) is 5800,6100,5600×2470,2450×550 (mm). Clients choose to install CLW Brand 8tons telescopic/knuckle crane boom.
The specification of LIUQI 8T knuckle crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
Liuqi 8T knuckle crane boom mounted on truck |
| Chassis type |
LZ1182M3ABT |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2550×3750,3900 |
| Cargo body dimension (L*W*H)(mm) |
5800,6100,5600×2470,2450×550 |
| GVW(kg) |
18000 (Kg) |
| Kerb Mass(kg) |
10500,10000 |
| Rated mass(kg) |
7305,7805 (Kg) |
| Approach angle/ Departure angle(mm) |
22/12 (°) |
| Front suspension/rear suspension(mm) |
1445/2455 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6JA200-50 |
| Displacement/Power(kw) |
6870 |
| Rated power |
147 |
| Manufacturer |
LIUQI single row driver cab |
| Chassis |
Drive Type |
4*2 |
| Wheelbase(mm) |
5100 |
| Tread(front/rear) |
1916/1860 (mm) |
| Transmission |
8 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
LIUQI |
| Number of spring axle(front/rear) |
10/10 |
| Tire Type |
10.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5800,6100,5600×2470,2450×550 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 8tons knuckle crane boom |
| The color of the whole truck is upon request. |
