2020s best price CLW brand dongfeng YUHU brand 12tons telescopic crane boom mounted on truck for sale,
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please feel free to send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Today, we will introduce hot sale Dongfeng Yulong 6*4 LHD 12tons telescopic crane boom mounted on truck as below
More pictures of dongfeng yulong 6*4 LHD 12tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price dongfeng yulong 240hp diesel 12tons truck with crane for sale
HOT SALE! dongfeng 240hp Euro 5 diesel 12tons telescopic truck with crane
HOT SALE! Dongfeng YULONG 6*4 LHD 12tons truck with crane, adopts dongfeng D913 single row driver cab, 5850+1350mm wheelbase, fastgear 9 speed gearbox, 5tons front axle/10tons double rear axles, 11.00R20 rail tires, PTO, yuchai 240hp/270hp Euro 5 diesel engine, etc.
The overall dimension of Dongfeng YUHU 12tons cargo truck with crane is 11950×2490×3850,3650(mm), while the dimension(L*W*H) of the cargo box body is 8300×2300,2400×550,800(mm). Client chooses to install CLW brand high quality telescopic/knuckle 10tons/12tons/14tons telescopic/knuckle crane boom.
The specification of dongfeng yuelong 12tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
Dongfeng Yulong 12tons telescopic crane boom mounted on truck |
| Chassis type |
EQ1250GLJ |
| Parameters |
Overall dimension length/width/height (mm) |
11950×2490×3850,3650 |
| Cargo body dimension (L*W*H)(mm) |
8300×2300,2400×550,800 |
| GVW(kg) |
25000 (Kg) |
| Kerb Mass(kg) |
14870 (Kg) |
| Rated mass(kg) |
8620 (Kg) |
| Approach angle/ Departure angle(mm) |
26/10 (°) |
| Front suspension/rear suspension(mm) |
1450/3300 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6A240-50 |
| Displacement/Power(kw) |
7520 |
| Rated power |
177 |
| Manufacturer |
Dongfeng |
| Chassis |
Drive Type |
6*4 |
| Wheelbase(mm) |
5775+1400 |
| Tread(front/rear) |
1940; 1900/1900 (mm) |
| Transmission |
Fastgear 9 speed gearbox |
| Braking system |
Air braking |
| Cab |
Dongfeng D913 single row driver cab |
| Number of spring axle(front/rear) |
9/13 |
| Tire Type |
11.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8300×2300,2400×550,800 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 12tons telescopic/knuckle crane boom |
| The color of the whole truck is upon request. |
