SHACMAN brand 8*4 LHD 336hp diesel 16tons telescopic crane boom mounted on truck for sale, cargo truck with crane for sale
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.More information, please feel free to contact with Ms. Anita.
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our CLW brand truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
SHACMAN brand 8*4 LHD 16tons telescopic crane boom mounted on cargo truck, adopts SHACMAN 8*4 LHD diesel truck chassis, Delong M3000 one row and a half driver cab, 2100+4575+1400mm wheelbase, WP10.336E53 weichai 336hp diesel Euro Ⅴ engine, fastgear 12 speed manual gearbox, MAN 7.5tons front axle/MAN 16tons dual grade rear axles, 12.00R20 rail tires, etc.
Clients choose to install CLW Brand high quality 12T/14T/16T telescopic crane boom. The cargo body dimension (L*W*H): 8300,8400×2450×600,800(mm).
More pictures of SHACMAN brand 16tons telescopic crane boom mounted on truck as below.
HOT SALE! Shacman Brand 16tons telescopic truck with crane for sale
High quality and competitive price Shacman Brand 16tons truck with crane for sale
the specification of SHACMAN brand 8*4 LHD 16tons telescopic crane boom mounted on truck as below
| Product name |
SHACMAN brand 8*4 LHD 16 tons telescopic crane boom mounted on truck for sale |
| Chassis type |
SX1310MB6 |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3980 |
| Cargo body dimension (L*W*H)(mm) |
8300,8400×2450×600,800 |
| GVW(kg) |
31000 (Kg) |
| Kerb Mass(kg) |
20800 (Kg) |
| Rated mass(kg) |
10070,10005 (Kg) |
| Approach angle/ Departure angle(mm) |
16/10 (°) |
| Front suspension/rear suspension(mm) |
1525/2400 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
WP10.336E53 |
| Displacement/Power(kw) |
9726ml/247KW/336hp |
| Manufacturer |
WEICHAI |
| Chassis |
Drive Type |
8*4 |
| Wheelbase(mm) |
2100+4575+1400 |
| Tread(front/rear) |
2036/2036, 1860/1860 (mm) |
| Transmission |
Fastgear 12 speed manual gearbox |
| Braking system |
Air braking |
| Cab |
SHACMAN Delong M3000 luxurious driver cab |
| Number of spring axle(front/rear) |
10/10/12 |
| Tire Type |
12.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8300,8400×2450×600,800 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 16T 5 sections telescopic crane boom |
| Lifting height |
21.5m |
| Working radius |
19.5m |
| The color of the whole truck is upon request. |
