high quality and best price Customized liuqi brand 8*4 LHD 350hp diesel folded truck with crane for sale, cargo truck with knuckle crane boom for sale
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. More information, please feel free to contact with Ms. Anita.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our liuqi brand 8*4 LHD350hp knuckle crane boom mounted on truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Customized liuqi brand 8*4 LHD truck with crane, adopts liuqi brand H5 one row and a half driver cab, 2100+4350+1350mm wheelbase, 10 speed gearbox, 2*5.5T front axles, 11.00R20 rail tires, air conditioner, etc.
The cargo body dimension of Liuqi Brand 8*4 LHD truck with crane is 7800×2470,2450×550(mm);client choose to install China made CLW brand high quality 12tons-16tons knuckle crane boom, etc.
More pictures of LIUQI brand 350hp 16tons knuckle crane boom mounted on truck as below
The specification of LIUQI brand 8*4 LHD 350hp diesel 16tons knuckle crane boom mounted on truck as below.
| Product name |
LIUQI brand 8*4 LHD 350hp diesel 16tons knuckle crane boom mounted on truck |
| Chassis type |
SX1181GP5 LZ1310M5FBT |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3780,3960 |
| Cargo body dimension (L*W*H)(mm) |
7800×2470,2450×550 |
| GVW(kg) |
31000(Kg) |
| Kerb Mass(kg) |
16160 (Kg) |
| Rated mass(kg) |
14710 (Kg) |
| Approach angle/ Departure angle(mm) |
19/11 (°) |
| Front suspension/rear suspension(mm) |
1512/2738 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6L350-50 |
| Displacement/Power(kw) |
8424ml/257KW/350hp |
| Manufacturer |
YUCHAI |
| Chassis |
Drive Type |
8*4 |
| Wheelbase(mm) |
2100+4350+1350, |
| Tread(front/rear) |
2080/2080; 1874/1874 (mm) |
| Transmission |
10 speed manual gearbox |
| Braking system |
Air braking |
| Cab |
LIUQI H7 one row and a half luxurious driver cab |
| Number of spring axle(front/rear) |
3/3/4 |
| Tire Type |
11.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
7800×2470,2450×550(mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install XCMG 14T 4sections telescopic crane boom |
| Lifting height |
19.1m |
| Working radius |
17.1m |
| The color of the whole truck is upon request. |
