Dongfeng 153 4*2 LHD 6.3tons/8tons telescopic crane boom mounted on truck for sale, Customized CLW brand 8tons cargo truck with crane for sale
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
HOT SALE! Dongfeng 153 4*2 LHD 180hp diesel 6.3tons/8tons telescopic crane boom mounted on truck, adopts dongfeng 153 one row and a half driver cab, 5100mm wheelbase, fastgear 8 speed gearbox, 5t front axle/10t rear axle, 10.00R20 rail tires, etc.
The overall dimension(L*W*H) of dongfeng 153 180hp 6.3tons truck with crane is 9000×2500×3850,3650(mm).While the dimension of the cargo box body is 6000×2300×550,600(mm). Client choose to install CLW Brand 6.3tons-8tons telescopic/knuckle crane boom mounted on truck.
More pictures of Dongfeng 8tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! dongfeng 8tons telescopic crane boom mounted on truck
Main technical parameters of dongfeng 4*2 LHD 153 6.3tons-8tons telescopic truck with crane as below.
| Product name |
Dongfeng 4*2 LHD 6.3tons telescopic crane boom mounted on truck for sale |
| Chassis type |
EQ1168GLJ4 |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2500×3850,3650 |
| Cargo body dimension (L*W*H)(mm) |
,6000×2300×550,600 |
| GVW(kg) |
15800 (Kg) |
| Kerb Mass(kg) |
11380 (Kg) |
| Rated mass(kg) |
4225 (Kg) |
| Approach angle/ Departure angle(mm) |
26/10 (°) |
| Front suspension/rear suspension(mm) |
1450/2450 |
| Fuel Type |
diesel |
| Max Speed |
110 |
| Engine |
Type |
YC6J180-50 |
| Displacement/Power(kw) |
6500ml/132KW/180hp |
| Manufacturer |
Yuchai |
| Type |
6 cylinders -in-line inter-cooling diesel Euro 5 engine |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
5100 |
| Tread(front/rear) |
1923/1865 (mm) |
| Transmission |
Fastgear 8 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Dongfeng 153 one and a half driver cab |
| Number of spring axle(front/rear) |
8/10+7 |
| Tire Type |
10.00R20 rail tires |
| Air-condition |
Original air conditioner |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5700,6000×2300×550,600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
3mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 6.3T/8tons telescopic crane boom |
| Rotation |
Full hydraulic, full rotation |
| The color of the whole truck is upon request. |
