CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
Chengli Special Automobile Co., Ltd., as a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of SINO TRUK WANGPAI truck with crane as below.
SINO TRUK WANGPAI brand 4*2 LHD 5T-6.3T telescopic crane boom mounted on truck for sale
SINO TRUK WANGPAI brand 4*2 LHD 5tons-6.3tons telescopic crane boom mounted on truck adopts WANGPAI 2080mm single row driver cab, 9 speed gearbox, 1080mm rear axle, 825R20 rail tires, power steering, air cut braking,abs, yunei 160hp diesel engine, 3900mm wheelbase, etc.
The specification of SINO TRUK WANGPAI brand 4*2 LHD 5tons-6.3tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
SINO TRUK WANGPAI brand 4*2 LHD 5tons-6.3tons telescopic crane boom mounted on truck for sale |
| Chassis type |
CDW1090HA1R5 |
| Parameters |
Overall dimension length/width/height (mm) |
7330×2260,2360×3500,3600 |
| Cargo body dimension (L*W*H)(mm) |
4300,4500×2100,2200×600 |
| GVW(kg) |
9495 (Kg) |
| Kerb Mass(kg) |
6800,7450 |
| Rated mass(kg) |
2500,1850 (Kg) |
| Approach angle/ Departure angle(mm) |
24/15 (°) |
| Front suspension/rear suspension(mm) |
1285/2145 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YNF40E2 |
| Displacement/Power(kw) |
3920 |
| Rated power |
115 |
| Manufacturer |
YUNNEI |
| Chassis |
Drive Type |
4*2 |
| Wheelbase(mm) |
3900 |
| Tread(front/rear) |
1750/1650 (mm) |
| Transmission |
9 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
Dayun single row driver cab |
| Number of spring axle(front/rear) |
11/11+9 |
| Tire Type |
825R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
4300,4500×2100,2200×600 |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 5tons-6.3tons telescopic/knuckle crane boom |
| The color of the whole truck is upon request. |
