Customized SINO TRUK HOMAN 4*2 130hp diesel Euro 5 4tons dump truck with crane for sale, HOT SALE! tipper truck with telescopic crane boom
Chengli Special Automobile Co., Ltd. is the leading manufacturer of truck with crane, truck mounted crane, dump truck with crane, cargo truck with crane, telescopic crane mounted on truck, etc. With many years’ experience in manufacturing, Chengli Special Automobile Co., Ltd. could manufacture and supply 4*2 small truck with crane, 4*4 truck with crane, 6*2 dump truck with crane, 6*4 cargo truck with crane, 8*4 crane monted on truck, etc. And the CLW brand cranes are from 2.5ton to 20 ton, and much bigger for different trucks. Chengli Special Automobile Co., Ltd. coulkd design and produce the trucks according to customers’ requirements. More information, please feel free to contact with us.
Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
The specification of SINO TRUK HOMAN 4*2 LHD 4tons dump truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
SINO TRUK HOMAN 4*2 LHD 4ton dump truck with crane(telescopic boom) |
| Truck chassis |
ZZ1048D17EB1 |
| Parameters |
Overall dimension length/width/height (mm) |
5995×2520×3470 (mm) |
| 3260*2150*550mm |
3260*2150*550(mm) |
| GVW(kg) |
4495 (Kg) |
| curb Mass(kg) |
3805 (Kg) |
| Rated mass(kg) |
495 (Kg) |
| Approach angle/ Departure angle(mm) |
20/16 (°) |
| Front suspension/rear suspension(mm) |
1175/1520 (mm) |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YN38CRE1 |
| Displacement/Power(kw) |
3760ml/70KW/95hp; |
| Manufacturer |
Yunnei engine; |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
3300 |
| Tread(front/rear) |
1825/1615 |
| Transmission |
Xiao 8 speed transmission, manual |
| Braking system |
Air braking |
| Cab |
2080mm single row driver cab |
| Number of spring axle(front/rear) |
3/5+3 |
| Tire Type |
825R16 |
| Air-condition |
Choose to fix |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
3450,3260×2400,2300,2150×600,550,400 (mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 4ton 4 sections telescopic crne boom |
| Max lifting mass |
4000kgs |
| Sections |
4 |
| Working radius |
11m |
| Lifting height |
13m |
| Rotation degree |
±360°full rotation, full hydraulic |
