The boom truck is also called boom arm crane truck, hydraulic crane truck, cargo crane, dump crane truck, truck with crane, etc. The boom truck is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional crane truck manufacturer in China, the crane capacity is from 2 ton to 160 ton. The drive type of chengli crane truck for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane can be crane, chengli crane, sany crane, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of SINO TRUK HOWO 14T flatbed truck with knuckle crane boom manufactured by Chengli Special Automobile Co., Ltd. as below.
Technical parameters of 6x4 RHD folding boom truck 14 ton manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Flatbed truck mounted crane |
| Drive Type |
6x4 |
| Gross Vehicle Weight(kg) |
25000 |
| Curb Weight (kg) |
13900 |
| Overall Dimensions L*W*H(mm) |
11990×2496×3665 |
| Engine |
Engine Brand |
SINOTRUK |
| Fuel Type |
Diesel |
| Power |
247kw/336HP |
| Emission Standard |
Euro II |
| Displacement(ml) |
9760 |
| Engine Type |
6 cylinders in line, water cooling, turbo-charged diesel engine, inter-cooling |
| Chassis |
Chassis Brand |
HOWO |
| Cab |
One row, flat cab, with single sleeper |
| Tire No. |
10+1 |
| Tire Specification |
12.00R20 Steel tire |
| Wheelbase (mm) |
4350+1300 |
| Axle No. |
3 |
| Gear Box |
HOWO 10 speed forward with 2 reverse, manual |
| Brake |
Air brake |
| Steering Wheel |
Left Hand Drive with power-assisted |
| Air Conditional |
Suitable for tropical climate |
| Crane and outrigger |
Crane |
Knuckle boom crane |
| Max lifting weight(kg) |
14000 |
| Max lifting height(m) |
14.8 |
| Max working radius(m) |
12.3 |
| Boom No. |
5 section |
| Outrigger No. |
2 pcs front outrigger, rear outrigger is optional |
| Rotation angle |
360 degree full rotation |
| Flatbed |
Flatbed Size(mm) |
7000x2400 |
| Ladders |
2 PCS manual ladders |
