brand new Japan ISUZU truck mounted 5 ton auger crane for telegraph pole drilling for sale, Good price ISUZU cargo truck with crane for sale
The cargo crane is also called truck mounted crane, crane truck, truck with crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by whatsapp/Wechat/Mob.: +86 13329899995.
ISUZU 700P 4*2 LHD 5tons telescopic crane boom mounted on truck for sale
ISUZU 700P 5T truck with crane adopts ISUZU brand 700P 4*2 LHD truck chassis, 4475mm wheelbase, ISUZU MLD 6 speed manual gearbox, ISUZU 4HK1-TCG40 190hp Euro 4 diesel engine, 4tons front axle/7tons rear axle, 8.25-16/8.25R15 tires, ISUZU 700P single row luxurious driver cab with power steering and air conditioner, etc.
The overall dimension (L*W*H) of ISUZU 5T telescopic crane boom mounted on truck is 7950×2307×3100(mm), and the cargo body box dimension (L*W*H): 5360×2150×450(mm). Client chooses to install CLW Brand high quality 4tons telescopic /knuckle crane boom.
More pictures of ISUZU brand 4*2 700P 190hp diesel 5tons telescopic crane boom mounted on truck with telegraph pole drilling as below.
The specification of ISUZU brand 4*2 700P 5tons telescopic crane boom mounted on truck as below.
| Product name |
ISUZU 4*2 LHD 5T telescopic crane mounted on truck for sale |
| Chassis type |
QL11009MARY |
| Parameters |
Overall dimension length/width/height (mm) |
7950×2307×3100(mm |
| Cargo body dimension (L*W*H)(mm) |
5360×2150×450 |
| GVW(kg) |
10000(Kg) |
| Kerb Mass(kg) |
5150 (Kg) |
| Rated mass(kg) |
4655(Kg) |
| Approach angle/ Departure angle(mm) |
20/10 (°) |
| Front suspension/rear suspension(mm) |
1110/2365 (mm) |
| Fuel Type |
diesel |
| Max Speed |
110 |
| Engine |
Type |
4HK1-TCG40 |
| Displacement/Power(kw) |
5193ml/139KW/190hp |
| Manufacturer |
Isuzu |
| Chassis |
Drive Type |
4×2 |
| Wheelbase(mm) |
4475 |
| Tread(front/rear) |
1680/1650 (mm) |
| Transmission |
ISUZU MLD 6 speed gearbox, manual |
| Braking system |
Air braking |
| Cab |
ISUZU brand 700P single row driver cab |
| Number of spring axle(front/rear) |
8/10+6 |
| Tire Type |
8.25-16/8.25R15 tires |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
5360×2150×450(mm) |
| Material |
Carbon steel |
| Side sheet thickness |
2mm thickness |
| Bottom sheet thickness |
2mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 5tons 4sections telescopic crane boom |
| Lifting height |
13m |
| Working radius |
11m |
| Aerial operation seat |
Yes |
| Hydraulic operation |
Yes, full hydraulic operation |
| Full rotation |
Yes, full rotation |
| installed with auger machine for pole drilling or brick crane |
