HOT SALE! FOTON 4*2 LHD 12T mobile crane truck for sale
Overall dimension(L*W*H): 10500*2350*3350
crane boom: 8m 5 sections veneer boom
full crane boom length: 33m
engine model: weichai 160hp
gearbox: fastgear
wheelbase: 4200mm
Tire specification: 900R20 rail tires
Main/auxiliary hoist: 12T/12T
Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.
If you're interested in our mobile crane truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of FOTON 12T Mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of FOTON 4*2 LHD 12T mobile crane truck is as below.
| Foton 12T mobile crane truck for sale |
| Total mass |
16000KGS |
Total mass(kg) |
12000 |
| Engine model |
WP3NQ160E61
Weichai 160hp
|
Main/auxiliary hoist |
12T/12T |
| Displacement/ power (ml/kw) |
2970/118 |
Crane boom |
8m 5 sections veneer crane boom |
| Gearbox |
fastgear |
Full crane boom length (m) |
33 |
| Overall dimension(L*W*H)(mm) |
10500*2350*3350 |
Big boom dimension(mm) |
580*460 |
| Wheelbase |
4200mm |
Back displacement top |
Standard |
| Tires pec |
900R20 rail tires |
Slewing bearing |
External gear |
| Front/rear axle(kgs) |
5400/10600 |
Slewing mechanism |
360°Arbitrary rotation |
| Outrigger Longitudinal/transverse span(mm) |
4800/6800 |
Beam |
new torque-fighting van beam |
| Steering type |
Hydraulic steering |
Power pump |
Triple-pump |
| Braking |
Air cut braking |
Operation room |
Advanced operation room |
| Others: double outriggers, fully covered floor, double-sided operation, negative angle, electronic throttle |
| Chosen part: Double Legs, motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level |
| Main parameters |
| Product name |
FOTON 12T mobile crane boom |
| Total mass(Kg) |
16000 |
Overall dimension(mm) |
10500×2350,2500×3350 |
| Rated mass(Kg) |
|
Driver cab seated person |
3 |
| Curb mass(Kg) |
15805 |
Curb mass(Kg) |
15805 |
| Axle No, |
2 |
Wheelbase (mm) |
4200 |
| Axle load(Kg) |
5400/10600 |
Max speed(Km/h) |
80 |
| Chassis main parameters |
| Chassis model |
BJ5164JQZHPDD-01 |
Manufacturer |
Foton |
| Approach/departure angle(°) |
20/18 |
Tire specification |
9.00R20 16PR |
| Steel spring |
10/12+9 |
Front tread(mm) |
1780 |
| Fuel type |
Diesel |
Rear tread(mm) |
1740 |
| Emission standard |
Euro Ⅵ |
| Engine model |
Manufacturer |
displacement(ml) |
power(Kw) |
| WP3NQ160E61 |
Weichai |
2970 |
118 |
