HOT SALE! new manufactured Tangjun 4*2 LHD 8T mobile truck crane, smaller 8tons mobile truck mounted crane for sale

Product Details:

Place of Origin:	China
Brand Name:	CLW
Certification:	CCC, ISO 9001

Payment & Shipping Terms:

Minimum Order Quantity:	1 unit
Price:	negotiable
Packaging Details:	in bulk package, waxed
Delivery Time:	20 days
Payment Terms:	T/T, L/C
Supply Ability:	20units/month

Contact Now

Detailed Product Description

Color:	Different Color Upon Request, Free To Paint Company Logo	Truck Chassis:	Chinamade TANGJUN LHD Diesel Truck Chassis
PRICE:	High Quality And Factory Direct Sale Price

HOT SALE! new manufactured Tangjun 4*2 LHD 8T mobile truck crane, smaller 8tons mobile truck mounted crane for sale

Mobile crane is also called truck crane, a kind of crane mounted on general truck chassis or special purpose truck chassis. The driving cabin and lifting operation cab are setted separately. The advantage of this kind of mobile truck crane is flexibility and moving quickly; while the weakness is work must be outrigger, cannot load driving and at the same time cannot work on the a soft or muddy field. And this kind of mobile truck crane is widely used for Engineering Constructions, such as Roads, bridges, buildings, emergency services, etc. The general engineering team, the construction industry and the electric power installment department, all needs the automobile crane.

Today, we will introduce Tangjun 4*2 LHD 8T mobile truck crane as below.

Overall dimension(L*W*H): 9600*2110*3000(mm)
Crane boom: 6.5m 5 sections out driving rope(with Retracting Rope)
Full Crane boom length: 28m
Engine power: weichai 130hp
Gearbox: wanliyang
Main/auxiliary hoist: 10T/5T

More pictures of tangjun 4*2 LHD 8tons mobile crane truck as below.

HOT SALE! new manufactured Tangjun 4*2 LHD 8T mobile truck crane, smaller 8tons mobile truck mounted crane for sale

Main technical parameters of TANGJUN 4*2 LHD 8T mobile crane truck manufactured by Chengli Special Automobile Co., Ltd. is as below.

Main technical parameters of
Total mass	9100kg	Total mass(kg)	8000
Engine model	WP2.3NQ130E61 weichai 130hp	Main/auxiliary hoist	10T/5T
Displacement/ power (ml/kw)	2289/96	Crane boom	6.5m 5 sections out driving rope(with Retracting Rope)
Gearbox	Wanliyang	Full crane boom length (m)	28
Overall dimension(LWH)(mm)	960021103000	Big boom dimension(mm)	450*300
Wheelbase	3360mm	Back displacement top	Standard
Tires pec	750R16 rail tires	Slewing bearing	external gear
Front/rear axle(kgs)	3300/5800	Slewing mechanism	360°Arbitrary rotation
Outrigger Longitudinal/transverse span(mm)	4200/4800	Beam	new torque-fighting beam
Steering type	Hydraulic steering	Power pump	Single pump
Braking	Air cut braking	Operation room	Advanced operation room
Others: Fully covered floor, double-sided operation, negative angle, electronic throttle
Chosen part: Double Legs, motor, computer, weighing apparatus, camera, rotating basket, air conditioning, level

Main technical parameters
Product name	Tangjun 4*2 LHD 8T mobile truck crane
Total mass(Kg)	9100	Overall dimension(LWH)(mm)	9600×2110,2150×3000,3110
Curb mass (Kg)	8905	Approach/departure ang;e(°)	13/9
Driver seated person	3	Front/rear suspension(mm)	1160/2180
Axle no.	2	wheelbase(mm)	3360
Axle load(Kg)	3300/5800	Max speed(Km/h)	75
Chassis
Truck chassis model	ZB5090JQZJPD6L	Truck chassis	Truck crane truck chassis
Overall dimension(LWH)(mm)	5990×2100×2300	Tire no/	6
Approach/departure angle(°)	13/15	Tire specification	7.50R16LT 16PR
Steel spring	6/9+5	Front tread(mm)	1700
Fuel type	Diesel	Rear tread(mm)	1650
Emission standard	Euro Ⅵ
Engine model	Manufacturer	displacement(ml)	power(Kw)
WP2.3NQ130E61	Weichai	2289	96
