Customized ISUZU brand 4*2 2 rows 18m telescopic aerial working platform truck for sale, High altitude operation truck

Customized ISUZU brand 4*2 LHD Double rows 18m telescopic aerial working platform truck for sale, HOT SALE! High altitude operation vehicle

The upper part of ISUZU 18m telescopic hydraulic bucket truck as below.

The working height is 14 meters, with four hydraulic telescopic legs (up and down extension and horizontal extension), a total of 12 oil cylinders, the legs are front V and rear H type, emergency pump, bucket belt 360 degrees Rotation, wireless remote control, and others are prepared according to factory standards.

1. The ISUZU 18-meter high-altitude operating vehicle adopts a telescopic straight arm structure. The operating arm is a 3-section telescopic type. The turntable can be operated or remotely operated. It can rotate 360 ​​degrees, four hydraulic outriggers, and the maximum load-bearing bucket. 200 kg, stainless steel hoarding, pattern anti-skid walking platform.

2. The working bucket adopts mechanical self-balancing design, its function is that the working bucket is always in a balanced state when working. The maximum extension angle of the forearm is up to 80° in order to adjust to the best working position.

3. Night work lights, operation lights can be installed on the operating table according to the customer's operating environment, making night work safer.

4. Computer control, automatic limit, dangerous work alarm, excellent safety performance. There is a display when getting off the car, which can display the working conditions of the whole car in real time.

5. The hexagonal working arm increases the strength, synchronously expands and contracts, the structure is compact, the working efficiency is high, and the working range is large. The telescopic oil cylinder is installed externally, and the chain telescopic mechanism is easier to observe the fault point and convenient for maintenance.

6. The outrigger adopts the front V and rear H-shaped structure, which has a larger bearing surface and higher stability; it can prevent the car beam from being deformed or broken. The outriggers are individually adjustable, and each outrigger can be adjusted separately according to the working ground environment. Even if the ground is uneven, the whole vehicle can be adjusted to a stable state. All outriggers are equipped with outrigger flashing lights for supporting during operation. The legs are profiled and a light alarm signal is issued.

7. The four vertical outrigger cylinders and the upper arm, lower arm, and forearm cylinders are all equipped with two-way hydraulic locks. The function is to lock the cylinders in place after reaching the required position to prevent accidents. The working arm is equipped with a two-way balance valve to make the working arm run more smoothly.

8. The main components of the vehicle including two-way hydraulic lock, two-way lock balance valve, hydraulic flow valve, hydraulic cylinder, engine start-stop emergency pump, operating system and control computer are all domestic well-known brands, and the core components are imported. Stable commutation, flexible and convenient operation; outriggers and working arms are interlocked, safe and reliable, to prevent misoperation.

If you're interested in our telescopic aerial working platform truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.

More pictures of ISUZU brand 600P double cabs 18m telescopic aerial working platform truck as below.

ISUZU 4*2 LHD double rows 18m telescopic aerial working platform truck adopts ISUZU 600P double-row driver cab with air conditioner and power steering, 3360mm wheelbase, ISUZU 4KH1CN5HS 130hp diesel Euro 5 engine, Isuzu MSB 5 speed gearbox, 4.8tons rear axle, 7.00R16 rail tires, Double circuit oil brake, etc.

Main technical parameters of ISUZU Brand 600P 4*2 LHD diesel 18m telescopic aerial working platform truck manufactured by Chengli Special Automobile Co., Ltd. as below.
