Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng LHD/RHD Diesel Truck Chassis | Drilling Depth: | 50m/80m/100m150m/200m, Etc. |
Customized 200m depth water well Drilling Machine mounted on truck for sale, HOT SALE! Water well drilling rig on truck
Drilling truck is also called mobile drilling platform, which is composed of automobile chassis, drilling equipment, transfer device, hydraulic system, tower and other parts. It is mainly used for the construction of seismic blast holes; the general survey exploration of oil, natural gas and solid minerals; the construction of engineering geological surveys for urban construction, railway and hydropower departments; shallow hydrogeological surveys and water well drilling.
Main features of CLW water well Drilling Machine as below.
Pressure and strong lifting, saving manpower and reducing labor intensity.
The hoist is a planetary hoist, which is flexible, safe and reliable in operation.
A reverse gear mechanism is added to the reduction box, and a handle can be manipulated to enable the gyrator to have three positions of forward rotation, stop, and reverse rotation, which makes it easy to unscrew and unload the active drill rod, save time and effort.
The mud pump has strong self-priming ability and adjustable 10-level flow.
The faucet is small in size, light in weight and reliable in sealing.
The active drill pipe has good rigidity and self-heavy weight. It can be pressurized by its own weight when drilling, and the drilling efficiency is high.
The lifting and landing derricks are operated hydraulically, which is convenient, safe and reliable.
The whole vehicle is equipped with four-stage hydraulic outriggers, which can adjust the extension length of any leg at will to adapt to different working places.
If you're interested in our water well drilling truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Main technical parameters of 200M depth water well drilling truck as below.
aximum drilling depth |
Drilling diameter ψ200mm, hourly depth 70m Drilling diameter ψ150mm, hourly depth 100m |
RRotating speed | Forward rotation / 57 96 169 Reverse rotation / 38 R/min |
MMaximum feed force/pull force | 30/50 KN |
GGive progress | 450 mm |
HHoisting single rope lifting force | 13 KN |
MMaximum working pressure of mud pump | 2 MPA |
MMaximum displacement of mud pump | 450l/min |
MMaximum pressure of hydraulic system | 8 Mpa |
The main advantage:
1 Hydraulic pressure and strong lifting, saving manpower and reducing labor intensity.
2 The hoist is a planetary hoist, which is flexible in operation, safe and reliable.
A reverse gear mechanism is added to the gearbox, and a handle can be manipulated to enable the gyrator to have three positions of forward rotation, stop, and reverse rotation, which makes the active drill rod easy to unscrew, time-saving and labor-saving.
3 The mud pump has a strong self-priming ability, with adjustable 10-level flow.
4 The faucet is small in size, light in weight and reliable in sealing.
5 The active drill pipe has good rigidity and self-heavy weight. It can be pressurized by its own weight when drilling, and the drilling efficiency is high.
6 The lifting and lowering derrick is hydraulically operated, which is convenient, safe and reliable to operate.
7 The whole vehicle is equipped with four sets of hydraulic outriggers, which can adjust the extension length of any leg at will to adapt to different working places.
8 The automobile transfer case is an integral, military off-road type.
9The forward and reverse rotation of the drilling rig can be realized on the console, and the operation is convenient and flexible.
