    Product Details:

    Place of Origin: China
    Brand Name: CLW
    Certification: CCC
    Model Number: CLW5185GLQZ3

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 30 days
    Payment Terms: T/T, L/C
    Supply Ability: 20 units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Truck Chassis: Chinamade SINO TRUK HOWO 4*2 LHD 160hp Diesel Engine Truck Chasssis
    Material: High Quality Carbon Steel Material Price: High Quality And Factory Direct Sale Price





    Customized SINO TRUK HOWO 4*2 160hp diesel 10cbm asphalt distributing vehicle for sale, HOWO bitumen distributing vehicle for sale



    Customized SINO TRUK HOWO 4*2 LHD asphalt tanker truck, adopts SINO TRUK HOWO LHD 2080mm one row and a half driver cab, YC4E160-33 160hp diesel engine, 6 speed gearbox, 3.6tons front axle/10.5tons rear axle, 9.00R20 rail tires, etc.



    The devices of SINO TRUK HOWO brand 4*2 LHD 10CBM intelligent type asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. is as below.



    1, the asphalt pump adopts high quality QGB950 (high viscosity asphalt pump, 950L/min).

    2, hydraulic system: Proportional valve (Taiwan EFBG-03-160-HF); Automatic reversing valve and overflow valve; radiator adopts Risheng brand; the model of hydraulic motor for asphalt pump: 05-110-BD31; hydraulic pump model: CBQ550-L or Power take off after engine GPC4-50R.

    3, control way: Intelligent touch screen computer control at the driver cab; control system: (Siemens, Germany), 36 sets intelligent asphalt spraying nozzles (one controls one).

    4, Heating method: Burner (Italy imported Riello brand burner model G20) + Automatic heating of heat transfer oil

    5, gasoline generator unit: 6KW

    6, spreading amount: 0.25-3.5L/㎡;

    7, asphalt distributing width: 4.5m, 48 sets spraying nozzles for 6m spreading width is selective (10000RMB additional).

    8, Distributing medium: emulsified asphalt, hot asphalt, SBS hot asphalt, etc.



    If you're interested in our HOWO 10,000Liters asphalt tanker truck, please send email to truck0011@163.com; or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.



    Performance parameter of SINO TRUK HOWO LHD 10cbm asphalt tanker truck manufactured by Chengli Special Automobile Co., Ltd. as below.

    Truck model: CLW5185GLQZ3

    Total mass: 18000kg

    Curb mass: 9180kg

    Overall dimension(L*W*H):8450×2500×3060mm

    Spreading width: 4700mm

    Distance between nozzles: 125mm

    Asphalt spreading amount: 0.2~3.5L/m2

    Working speed:1.5--20km/h

    Heating way: Italian imported burner heating G20(200,000 Kilocalorie/hour)

    Spreading medium: emulsified asphalt, hot asphalt, SBS BS modified pitch, modified emulsified asphalt

    Spreading inaccuracy:±2%



    More pictures of SINO TRUK HOWO 4*2 LHD 10,000Liters asphalt tanker distributing vehicle as below.

    Customized SINO TRUK HOWO LHD 160hp diesel 10cbm asphalt distributing vehicle for sale, HOWO bitumen distributing vehic

    Customized SINO TRUK HOWO LHD 160hp diesel 10cbm asphalt distributing vehicle for sale, HOWO bitumen distributing vehic

    HOT SALE! 10,000Liters asphalt tanker truck for sale

    Customized SINO TRUK HOWO LHD 160hp diesel 10cbm asphalt distributing vehicle for sale, HOWO bitumen distributing vehic

    10,000Liters bitumen distributing tanker truck for sale

    Customized SINO TRUK HOWO LHD 160hp diesel 10cbm asphalt distributing vehicle for sale, HOWO bitumen distributing vehic

    customized HOWO 10CBM asphalt tanker truck for sale



    (三)main parts of asphalt tanker truck as below

    Item Name Model, specs Affiliation System Remark
    1 Truck chassis ZZ1167 Chassis 250mm boom, power steering and air cut baking, etc.
    2 Engine YC4E160-33
    3 Gearbox 6 speed gearbox, manual
    4 Tires specification 9.00R20
    5 Front/rear axle Front axle: 4.5T;rear axle:10T,
    5 Asphalt tanker volume 10cbm Tanker High quality carbon steel
    6 Thickness of insulating layer 50mm thickness Rock wool insulation
    7 Covered with stainless steel 1mm thickness 1mm stainless steel plate
    8 PTO Specialized for spreading vehicle Source of work motivation
    9 Hydraulic pump CBQ550-L Hydraulic system Tianjin
    9 Proportional Valve EFRD-G03-160-5-31 Northman
    10 SOLENOID Directional Valve SWH-G03-D24-20 Northman
    11 overflow valve MT-02 Northman
    12 radiator AH1012T GUANGZHHOU Hercules
    11 Motor for hydraulic pump 05-110BD40 Tianjin/ningbo
    12 Asphalt pump QGB950 Asphalt spreading system shanggui, 950L/min
    13 Nozzles nos. 36sets Control mode:1 controls 1
    14 Handlance 5m length hose+1.5m length manual nozzle corner spraying
    15 Burner G20(200,000万kilocalorie/hour) Heating system Italy Riello
    16 Heat conducting oil pump RY32-32-160 Hebei
    17 Heat conducting oil pump motor 380V-2.2KW-2 grade Anhui liu’an
    18 Control system mode Driver Cab touch-screen computer control +rear working platform control(reserve) Controlling system The control system adopts USA cylindro controller.,faster and smoother operation, low failure rate
    19 Velocity sensor Ni5-G12 GERMAN TURCK
    20 Temperature controller Pt100 SHANGHAI XINGHUI
    21 Generator LT10000EN3-4 Power system Lutian 6kw gasoline generator unit
