Customized FOTON AUMAN RHD 8T telescopic crane boom mounted on cargo truck for sale,good price new 8T truck with crane for sale,
The boom truck is also called cargo crane truck, hydraulic crane truck, boom truck with crane, dump crane truck, etc. The boom truck is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional boom truck manufacturer in China, the crane capacity is from 2 ton to 160 ton. The drive type of chengli crane truck for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane can be crane, chengli crane, sany crane, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck with crane in China since 2004s. With many years' development, Chengli Special Automobile Co., Ltd. could supply truck mounted crane from 1ton to 20ton and heavy duty truck with cranes.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
FOTON AUMARK 4*2 RHD 240hp diesel truck with crane adopts FOTON AUMARK RHD truck head, 5150mm wheelbase, 8JS105TA 8 speed gearbox, 10tons rear axle, YC6A240-33 240hp diesel engine, 11R22.5 tires*6+1, air cut braking, 24V batteries, etc.
The cargo body dimension (L*W*H) of FOTON AUMARK cargo truck with crane is 6000×2400×550,600
(mm); while the overall dimension(L*W*H) of FOTON AUMARK crane mounted on cargo truck is 9000×2500×3580(mm). And this cargo truck with crane is installed with 6.3T/8T telescopic crane boom.
More pictures of FOTON AUMARK 4*2 RHD 240hp diesel cargo truck with crane manufactured by Chengli Special Automobile Co., Ltd.
main technical parameters of FOTON AUMARK 4*2 RHD 240hp diesel cargo truck with telescopic crane boom manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
FOTON AUMARK 4*2 RHD 8tons knuckle boom mounted on truck for sale |
| Chassis type |
BJ1188 |
| Parameters |
Overall dimension length/width/height (mm) |
9000×2500×3580(mm) |
| Cargo body dimension (L*W*H)(mm) |
6000×2400×550,600 |
| GVW(kg) |
18000(Kg) |
| Kerb Mass(kg) |
12000(Kg) |
| Approach angle/ Departure angle(mm) |
18/9 (°) |
| Front suspension/rear suspension(mm) |
1270/2580 (mm) |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
YC6A240-33 |
| Displacement/Power(kw) |
9755ml/177KW/240hp |
| Manufacturer |
YUCHAI |
| Chassis |
Drive Type |
4*2 |
| Wheelbase(mm) |
5150 |
| Tread(front) |
3050 |
| Tread(rear) |
1820 |
| Rear axle |
10tons rear axle |
| Transmission |
8 speed gearbox, manual |
| Tire Type |
11R22.5 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
6000×2400×550,600 (mm) |
| Material |
Carbon steel |
| Side sheet thickness |
3mm thickness |
| Bottom sheet thickness |
3mm thickness |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install XCMG 8tons 4 sections telescopic crane boom |
| Working radius |
Approximate 11.8m |
| Max lifting height |
Approximate 13.5m |
| The color of the whole truck is upon request. |
