The bulk feed truck body consists of horizontal auger, vertical screw conveyor, lifting screw conveyor, hydraulic push rod, electric control part and box.
- top-loading brand motor, complete high quality Electric control system; electronic phase interlock protection such as under-phase, under-voltage and anti-reverse.
- The tank can be divided into 2-5 boxes, so that it can be unloaded separately, that is, one car can transport a variety of feeds, and it can be controlled at will. The binning mechanism adjusts the control, and can control the opening degree at will, and accurately control the unloading speed.
- The size and tonnage of the tank can be used as the chassis of the car according to the existing idle vehicles of the customer or the local agricultural vehicle. The special conditions such as the discharge level of the feed mill and the height of the tower can be customized according to the actual situation.
- The loading capacity is based on the volume of the tank. The actual loading will vary depending on the type of feed.
-
The advantages of CLW brand bulk feed tanker transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1, the feed tank material: adopts high quality carbon steel,
2, The feed tank is with 2 compartments to load 2 kinds of feeds with separate discharging operation system.
3, Sealed transportation and reducing wastage, saving manpower and bag price, easy operation and maintenance.
4, Low center of gravity, reliable loading and discharging, good appearance with high quality.
If you're interested in our bulk feed truck, please send email to truck0011@163.com or talk to Anita by WHatsapp: 0086 13329899995.
Main technical parameters of Dongfeng TIANJIN 10T BULK FEED TRUCK is asbelow.
| Main technical parameters |
| Product name |
Dongfeng tianjin LHD 4*2 bulk feed truck |
| Overall dimension(L*W*H) (mm) |
7700×2500×3550 |
| Total mass(Kg) |
12490 |
| Max speed |
85km/h |
| Transmission |
6 speed transmission, manual |
| Tyre nos. |
6+1*9.00R20 |
| Axles |
3.6ton front bridge/6ton rear bridge |
| Driver cab |
Dongfeng TIANJIN luxurious driver cab |
| Engine model |
B190 33/B210 33 |
| Engine emission standard |
Euro 3 |
| Engine power |
190HP/210HP diesel engine |
| Engine displacement(ml) |
5900ml; 5900ml |
| Feed tank |
| Volume |
20/22/24cbm |
| Loading capacity |
10-12tons(According to the proportion( feed proportion is from 0.45tons/m3 to 0.55tons/m3) |
| Discharging way |
Hydraulic system discharging or 3 phases 380 volts electric system discharging |
| Compartments |
2 compartments with 2 different kinds of feed pellet |
| Discharging auger length |
6.86m |
| Average discharging speed(kg/min) |
500-600 kg/min or 1m3/min |
| Full discharging time (minutes) |
10 |
| Rotation angle of auger when discharging |
±180 degree |
| max elevation angle of auger when discharging |
60 degree |
| Residual rate |
No more than 0.10 |
Bulk feed delivery truck is main used for delivering, loading and discharging of feed pellets of different feed factories, large-type poultry farms, and also for transporting some non-corrosive feed pellets, such as pellets from pharmaceutical factory and turnover of grain depots, etc. the feed trucks manufactured by Chengli Special Automobile Co., Ltd. can transporting various feed pellet with the different compartments, the dream transporting vehicles for poultry farms and feed factories.
Chengli Special Automobile Co., Ltd. Is the leading manufacturer and supplier of feed trucks in China. With many years’ development, we Chengli Company can manufacture and sell farm-oriented feed trucks(electronic system discharging or hydraulic system discharging) from 8m3 to 40m3 and 40m3-50m3 animal feed transported semitrailer, etc. And more and more CLW Brand feed trucks have been exported all over the world. More information, please kindly contact Ms. Anita.
