New hydraulic mobile SHACMAN 14tons telescopic boom grove grab back installed truck mounted crane remote control 14ton crane cheap price
As a professional cargo truck crane supplier in China, we Chengli Special Automobile Co., Ltd. manufacture the crane boom is from 2 ton to 160 ton. The drive type of our truck crane for sale are 4x2, 6x2, 6x4,8x4,etc. The truck mounted crane for sale are telescopic boom truck mounted crane, knuckle boom truck mounted crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane for truck can be crane, chengli crane, sany crane, unic crane, kanglim crane, etc.
Truck crane ,also called boom truck crane,mobile truck crane , truck mounted crane , hydraulic folding truck crane,telescopic straight boom crane,truck with crane , crane lorry,hydraulic arm crane for trucks,pickup truck mounted crane,light truck with crane,folding arm hydraulic lift platform,hydraulic crane telescopic boom,mobile crane price ,self loader truck with boom crane,new forland lorry truck mounted crane,telescopic boom truck mounted crane,flatbed knuckle boom truck crane,6 wheelers truck with crane boom truck cranes sale etc.
1.We are professional manufacturers to do the special vehicles . We are supply all brands of special truck , north benz(beiben) , Faw , Foton , Shaanxi ,Sinotruck , Jac , Jmc , Isuzu ,Dongfeng all available .
2.the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4
3.We can provide LHD (left hand drive) or RHD (right hand drive) vehicles .
A crane mounted on a truck carrier provides the mobility for this type of crane. This crane has
two parts: the carrier, often referred to as the Lower, and the lifting component which includes the
boom, referred to as the Upper. These are mated together through a turntable, allowing the upper
to swing from side to side. These modern hydraulic truck cranes are usually single-engine machines, with the same engine powering the undercarriage and the crane. The upper is
usually powered via hydraulics run through the turntable from the pump mounted on the lower. In
older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the
crane down the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turntable of aging newer design cranes.
Customized SHACMAN brand 8*4 LHD 14T knuckle crane boom mounted on cargo truck for sale,
Customized SHACMAN brand 8*4 LHD 14T knuckle crane boom mounted on cargo truck adopts Shacman M series low-top luxurious driver cab, 2100+4575+1400mm wheelbase,
SHACMAN brand 8*4 LHD 16T knuckle crane boom mounted on truck for sale, 10JSD180+QH50 gearbox, WP10.380E22 380hp diesel Euro 2 engine, MAN 9.5T front axle, 400L aluminum alloy tanker, 12.00R20 rail tires, etc.
Clients choose to install CLW Brand high quality 30tons knuckle crane boom. The cargo body dimension (L*W*H): 8000x2450x600 (mm). There are rear manual ladders at the rear part of the cargo body. Choosing to install XCMG brand 14T knuckle crane boom (the working height is 14m and the working radius is 12.1m, full rotation with aerial operation seat).
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp: 0086 13329899995.
SHACMAN brand 8*4 14T cargo truck with crane for sale
The specification of SHACMAN brand 8*4 LHD 14tons knuckle crane boom mounted on truck as below
| Product name |
SHACMAN brand 8*4 LHD 14tons knuckle crane boom mounted on truck for sale |
| Chassis type |
SX1310 |
| Parameters |
Overall dimension length/width/height (mm) |
12000×2550×3980 |
| Cargo body dimension (L*W*H)(mm) |
8000×2450×600,800 |
| GVW(kg) |
31000 (Kg) |
| Kerb Mass(kg) |
20800 (Kg) |
| Rated mass(kg) |
10070,10005 (Kg) |
| Approach angle/ Departure angle(mm) |
16/10 (°) |
| Front suspension/rear suspension(mm) |
1525/2400 |
| Fuel Type |
diesel |
| Max Speed |
90 |
| Engine |
Type |
WP10.380E22 |
| Displacement/Power(kw) |
9726ml/280KW/380hp |
| Manufacturer |
WEICHAI |
| Chassis |
Drive Type |
8*4 |
| Wheelbase(mm) |
2100+4575+1400 |
| Tread(front/rear) |
2036/2036, 1860/1860 (mm) |
| Transmission |
10JSD180+QH50 manual gearbox |
| Braking system |
Air braking |
| Cab |
SHACMAN M3000 luxurious driver cab |
| Number of spring axle(front/rear) |
10/10/12 |
| Tire Type |
12.00R20 |
| Upper part(cargo van and crane boom) main parameters |
| Upper body |
Cargo body dimension |
8000x2450x600 |
| Material |
Carbon steel |
| Painting |
Upon request |
| Crane boom main parameters |
| Crane boom |
Choose to install CLW brand 14T 5 sections knuckle crane boom |
| Lifting height |
14m |
| Working radius |
12.1m |
| The color of the whole truck is upon request. |
