China good quality refrigerated truck with meat hooks for sale, factory sale refrigerator truck for frozen meats
The refrigerated van truck of Chengli Special Automobile Co., Ltd. is at the high end. The van sheet is adopting the leading 16m length hydraulic veneer press one-formed casting.
The exterior and interior van materials choose the high quality glass steel plate; the medium is PU foam insulation materials. The sides is glued together by the natural resin, like a sealed plates, and fastened by the high strength screws when piecing. And also there is more layers high quality rock wool, making sure the insulation and the stability. The van frames are edged with aluminum alloy, the fittings adopts stainless steel material.
The whole van truck is with handsome looking, long lifetime (2 times of the other refrigerated van), A grade insulation standard. Comparing to the other common refrigerated van trucks, the fixedness and airtight is the best; lighter mass, strong dent resistance, non-leakage, etc.
Chengli Special Automobile Co., Ltd can manufactures and sales refrigerated trucks with mass production. And also we can design and manufacture the refrigerated truck according to customer’s requirements. Any information, please contact Ms. Anita Deng. Please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Foton RHD 3ton refrigerated truck for sale |
| Drive Type |
4*2 RHD |
| Real loading capacity (kg) |
3,000kgs-5,000kgs |
| Payload (kg) |
2900 |
| Seating person |
2-3 |
| GVW (kg) |
6495(Kg) |
| Curb Weight (kg) |
3400(Kg) |
| Overall Dimensions (L*W*H) (mm) |
5995×2150,2200×2920(mm) |
| Insulation van dimension(L*W*H)(mm) |
4055×1940×1770(mm) |
| Driver cab |
Foton Aumark RHD 1800mm single row luxurious driver cab |
| Engine |
Engine Model |
ISF3.8s3141 |
| Engine Brand |
Cummins engine |
| Fuel Type |
Diesel |
| Max output (hp/rpm) |
141hp(105KW)/2600 |
| Emission Standard |
Euro Ⅲ |
| Capacity (cc) |
3760 |
| Engine type |
4 cylinders in line, inter-cooling diesel engine |
| Chassis |
Chassis Brand |
Foton |
| Tire Specification |
7.00R15 |
| Wheelbase (mm) |
3360 |
| Axle No. |
2 |
| Rear axle |
5.5ton rear axle |
| Steering Wheel |
RHD( right hand drive) with power steering, LHD is selective |
| Gear Box |
5 speed gearbox, manual |
| Brake |
Air brake |
| Air-conditioner |
No, the air-conditioner is selective |
| Cold Room |
Box inner dimension(mm) |
4055×1940×1770(mm) |
| Box Side |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. |
| Box Floor |
Baseboard adopts anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. |
| Doors |
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc.
The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability.
Door edgings, door locks and accessories use stainless steel materials. |
| Meat hooks |
There will be 100 units of stainless steel double sides’ meat hooks and three slid guides on the roof top. |
| Cooking unit |
High quality Korea Hanya brand frozen cooling unit |
Hanya brand frozen cooling unit-DM-450C, the temperature can be adjusted from 0℃ to -18℃. And the cooling unit can be adjusted at the driver cab. |
