18cubic meters bulk grains farm delivery truck for sale, best price bulk grains self-sucking discharging van truck
The bulk grain is with simple structure, reliable function, easy control, non-pollution, etc.
The advantages of the bulk grain delivery trucks can transport rice, wheat, soya bean, corn, sorghum, rapeseed, sesame seed, peanut, etc. The bulk grain trucks can save much man power, reducing discharging problem, non-disturb from enviorment and weather, improving the safety. The bulk grain delivery truck is the the perfect transportation vehicle for Grain Bureau/Administration, subsistence plants, Flour processing factories, etc.
If you're interested in our truck, please send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of hot sale 18m3 bulk grains transported truck manufactured by Chengli Special Automobile Co., Ltd. as below
The hot sale bulk grains delivery truck is with the truck model of CLW5100ZLSB4. And the overall dimension of the van truck for bulk grains is 5000*2360*2100(mm). And the overall dimension of the whole bulk grains delivery truck is 7400×2390×3590mm. And the real loading capacity is 18 cubic meters. According to the density of different grains, the real load is different, such as rice is about 10ton and the wheat is 12.5ton. And sealed van volume is 20cubic meters, and the real loading capacity is 18-19cbm. The sucking hose is 10m-15m, and the discharging speed is about 8-10ton/hour.
The bulk grains truck can choose forland, dongfeng, yuejin, isuzu, etc. And this hot sale one is forland truck chassis, yuchai 130hp/yunnei 130hp, 8.25-20 nylon tyre, 9ton rear axle/3ton front axle, 5 speed transmission, air braking, power steering, etc. And the grains van can be liftee up to 5.8m.
Main parameters of Forland 18cubic meters bulk grains transported truck for sale (CLW5120ZLS4) as below
| Forland 18cubic meters bulk grains transported truck for sale (CLW5120ZLS4) |
| Product name |
bulk grain delivery truck |
Chassis model |
BJ1102VDPEA-G1 |
| Engine |
Manufacturer |
Displacement(ml) |
Power(kw) |
YN38CRD1
YC4D130-41 |
Yunnei power
Yuchai |
3760
4200 |
95
96 |
| Emission standard |
Euro 4/ Euro 3/Euro2 |
Fuel type |
Diesel |
| Overall dimension |
7400×2360×3550(mm) |
Steering type |
Power steering |
| Total mass |
9935(Kg) |
Rated mass |
2300(Kg) |
| Curb mass |
7440(Kg) |
Max speed |
80(km/h) |
| Approach/departure angle |
29/14(°) |
Front/rear suspension |
1175/2325(mm) |
| Axle load |
3775/6160 |
Wheelbase |
3900(mm) |
| Alxe nos. |
2 |
Steel spring |
9/11+8 |
| Fuel consumption |
22.94/23.07 |
Tyres |
8.25-20*6+1 |
| Gearbox |
5 speed gearbox |
Rear axle |
8.5tons 1092 rear axle |
| Driver cab |
Ait cut brake with 250mm double layers boom |
Driver cab |
Forland 1860mm one row and a half turnover driver cab with power steering and warm air |
| Front tread |
1750mm |
Rear tread |
1654mm |
| Special devices |
Hydraulic gear pump |
Techanical data |
Sealed grain van volume |
20cbm |
|
| Hydraulic motor |
1 unit |
Real grain van volume |
18-19cbm |
|
| High pressure fan |
1 unit |
Sucking pipe length |
10-15m |
|
| Hydraulic control valve |
|
Sucking speed |
8-10T/h |
|
| dust catcher |
1 unit |
Overall dimension(mm) |
7400×2360×3550(mm) |
|
| Inlet pipe |
1 unit |
Grain van dimension (mm) |
5000*2360*2100 |
|
| Loading capacity for wheat(kgs) |
11,000-12,000kgs |
Loading capacity for rice(kgs) |
10,000kgs |
|
| |
|
|
|
|
|
|
|
Grains transported truck is also called self-sucking and self-discharging grains delivery truck, grains tipper truck, etc. It is a kind of special purpose vhicle refitted sealed grains van body, hydraulic gear pump, hydraulic motor, high pressure fan, hydraulic lifting mechanism on the the second type cargo truck chassis. The bulk grains truck is with the advantages of reasonable design, reliable performance, easy operation, non-pollution to the grains, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer of grain trucks in China. More information, please feel free to contact with us.Bulk grain transportation vehicle is also called slef-loading and unloading bulk grain carrier and grain carrier truck. It’s kind of grain truck refited on the second type chassis with sealed grain van, high pressure fan, hydraulic lifting mechasm, etc.
The bulk grain is with simple structure, reliable function, easy control, non-pollution, etc.
The advantages of the bulk grain delivery trucks can transport rice, wheat, soya bean, corn, sorghum, rapeseed, sesame seed, peanut, etc. The bulk grain trucks can save much man power, reducing discharging problem, non-disturb from enviorment and weather, improving the safety. The bulk grain delivery truck is the the perfect transportation vehicle for Grain Bureau/Administration, subsistence plants, Flour processing factories, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer of grain trucks in China. More information, please feel free to contact with us.
