Main Features of FOTON AUMAN 6*4 12CBM truck mounted Concrete Mixer Drum
•Italy imported pump,motor and decelerator, long service life
•High quality Q345 mixing drum, reliable
•Superior cleaning system, large water tank
•Low oil consumption and maintenance
•15 years experience with ISO9001 and CCC Certification
•Factory direct sales, competitive price
Technical parameters of foton Auman 6x4 12m3 concrete mixer truck for sale
|
Items
|
Descriptions
|
Specifications and Types
|
|
General
|
Truck Name
|
Concrete mixer truck
|
|
Drive Type
|
6*4, left hand drive
|
|
Gross Vehicle Weight(kg)
|
25000
|
|
Curb Weight (kg)
|
14005
|
|
Overall Dimensions L*W*H(mm)
|
9780×2500×3980
|
|
Engine
|
Engine Model
|
WP10.340E32
|
|
Engine Brand
|
Weichai
|
|
Fuel Type
|
Diesel
|
|
Power
|
250kw/340HP
|
|
Emission Standard
|
EuroIII
|
|
Displacement(ml)
|
9726
|
|
Engine Type
|
6 cylinders in line,water cooling, turbo-charged diesel engine,inter-cooling
|
|
Chassis
|
Chassis Brand
|
FOTON/AUMAN
|
|
Chassis Type
|
Concrete mixer truck chassis
|
|
Tire No.
|
10
|
|
Tire Specification
|
11.00-20 Steel tire
|
|
Wheelbase (mm)
|
4100+1350
|
|
Axle No.
|
3
|
|
Gear Box
|
FAST 9 speed forward with 2 reverse, manual
|
|
Brake
|
Air brake
|
|
Clutch
|
430 single dry clutch
|
|
Air conditional
|
Suitable for tropical climate
|
|
Superstructure
|
Valid mixing volume
|
12m³
|
|
Mixing drum
|
Pyriform Structure,Q345
|
|
Hydraulic motor
|
Italy PMP
|
|
Hydraulic pump
|
Italy PMP
|
|
Reducer
|
Italy PMP
|
|
Water tank volume
|
400 liter
|
|
|
|
|
More information, please feel free to contact with us.
Whatsapp: +86 13329899995
Wechat: 504873236
Skype: truck0011
QQ: 504873236
More Pictures of Foton Auman 6x4 truck mounted concrete mixer
hydraulic system of concrete mixer truck
Cleaning system of concrete mixer truck
