Place of Origin: | China |
Brand Name: | CLW |
Certification: | ASME standard, ISO 9001 |
Minimum Order Quantity: | 1 UNIT |
---|---|
Price: | 20,000-50,000USD/UNIT |
Packaging Details: | in bulk package |
Delivery Time: | 40 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20 units/month |
Color: | Different Color Upon Request | Material: | High Quality Q345R Material For Lpg Gas Pressure Vessels |
---|---|---|---|
Price: | Factory Direct Sale, High Quality With Best Price | Manufacturing Standard: | US ASME Standard Or ISO 9001 |
High Light: | LPG storage tank,LPG tank trucks,LPG tank semitrailer |
CLW brand 3 axles 56,000L LPG gas tanker semitrailer for propane for sale, BPW axles gas cooking propane trailer
3 axles 56cbm LPG tanker semitrailer for propane, the wheelbase of the semitrailer is 6865+1310+1310(mm), the overall dimension 12700*2500*3975(mm), the volume is 56cbm; the transporting medium is propane, and the designed pressure is 1.61Mpa, the filling ratio is 0.42.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves,3 axles 13ton BPW bridges(FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
The LPG tanker semi-trailer is line with the GB150-1998, <<Supervision Regulation On Safety Technology for Pressure Vessel>>, <<Regulation of Safety Supervision for Liquefied Gas Tank Car>>.
Chengli Special Automobile Co., Ltd. is the leading manufacturer of LPG pressure vessels, LPG tank trucks, LPG storage truck, LPG gas tank, LPG tank trailer, etc. in China since 2004s. With many years’ experience in manufacturing and selling, Chengli Special Automobile Co., Ltd could offer storage tanks series (10cbm-100cbm propane storage tank, 10cbm-100cbm liquid ammonia pressure vessels), LPG gas trailers (2 axles LPG trailer for propane, 3 axles LPG trailer for propane, 3 axles LPG trailer for methoxymethane, 3 axles LPG semitrailer for liquid ammonia), and LPG tanker trucks for loading propane, propene, liquid ammonia, isobutene, propylene, etc.
More infomation, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat: +86 13329899995.
ASME standard 56cbm lpg gas trailer for South Africa
main technical parameters of hot sale 56cbm LPG tanker semitrailer for LPG GAS as below
Loading medium | Propane | Medium characteristic | flammable and combustible | Safety vavle 2*DN80 |
|
Curb mass(kg) | 17900 | Tanker | Designed pressure(MPa) | 1.61 | Designed standard ASME |
Loading capacity (kg) | 23520 | Filling ratio(kg/m3) | 420 | ||
Total mass(kg) | 40000 | Main material | Q345R | ||
Wheelbase(mm) | 6865+1310+1310 | Cylinder thickness(mm) | 16 | ||
Front/rear suspension(mm) | -/1540 | Head thickness(mm) | 18 | Chengli Special Automobile Co., Ltd. | |
Overall dimension(L*W*H) | 12700*2500*3965 | Tanker dimension(inner diameter*thickness*length)(mm) | 2450*16*12330 |
56cbm LPG tanker semitrailer for LPG GAS adopts 13ton BPW triple axles, 12+1 sets 12.00-20 vacuum tyre, , JOST 28ton outrigger, JOST 50# traction pin, fire extinguisher bottles, anti-static tape., steel flippers, ABS etc.
The standard devices are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, steel flippers, ABS etc.
The LPG tanker semi-trailer is line with ASME standard.
More pictures of high quality and competitive price bulk lpg gas propane trailer manufactured by Chengli Special Automobile Co., Ltd.
