The tank volume is 57cbm. The tanker material adopts Q345R. The propane design pressure is 0.42Mpa, the test pressure is 2.1Mpa, designed temperature is 50 degree, filling volume is 0.42, and corrosion allowance is 1mm. The tanker thickness is 12mm, one ball head (8mm thick) and one ellipse head (12mm thick). The loading medium is LPG (Propane), the medium density is 442kg/m3. And the tanker will be with the Flammable and explosive identification.
The standard devices of the 57cbm LPG tank semitrailer for propane are single outlet, double side loading and unloading, double valves boxes, double toolboxes, safety valve, temperature gauge, pressure gauge, cut off valves, 3 axles 13ton BPW bridges (FUHUA bridge), 12 sets12.00 vacuum tyres and 1 set spare tyre, JOST outriggers, JOST traction pin, one extinguisher bottle, steel flippers, with ABS, etc.
|
|
Function introduction
|
“CLW” brand LPG storage tanker semitrailer manufactured by Chengli Special Automobile Co., Ltd. adopts scientific leading treatments, assuring the lowest Shrinkage and highest
dimension stability at the low temperature. The advantages of the LPG storage tanker are low-temperature storage, easy transporting, safe and reliable, easy maintain, etc. The LPG storage tankers are suitable for storing LPG, liquid ammonia, carbon disulfide, epoxyethane, gasoline, butane, propane, propene, etc.
All the LPG tank trucks and LPG pressure vessels manufactured by Chengli Special Automobile Co., Ltd. are line with the GB150-1998<steel pressure vessel>, <Supervision Regulation on Safety Technology for Pressure Vessel, Regulation of Safety Supervision for Liquefied Gas Tank Car>.
|
