Color: | Different Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Material: | High Quality Q345R Material For Lpg Gas Pressure Vessels |
16 metric tons skid lpg gas filling plant for Nigeria Africa, 16MT mobile skid-mounted propane gas refilling station
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of lpg gas pressure vessels in China. With many years'development, Chengli Special Automobile Co., Ltd. could manufacture and supply surface/underground lpg gas storage tank, lpg gas tank semitrailer, skid lpg gas refilling plant, lpg gas truck, lpg gas bobtail vehicle, etc. More information, please feel free to contact with Ms. Anita.
1. gas refueling station,lpg gas station, lpg filling plant
2. 5ton 10ton 20ton 30ton 40ton 50ton 60ton lpg filling plant
If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/wechat/Mob.: +86 13329899995.
The main parameters of hot sale 40m3 16Metric tons skid lpg gas refilling plant as below
Technical specification |
parameters |
Subject |
parameters |
|||
tank |
Item Number |
40M3 LPG tank |
Liquid Indictor |
Model |
UHZ-518C14 |
|
|
Overall size(mm) |
10040*2324*2914 |
|
Version |
Magnetic |
|
|
Net weight(Kg) |
8630 |
|
Normal pressure |
2.5Mpa |
|
|
Vessel type |
III |
|
Scope of testing |
50-2300mm |
|
|
Designing pressure |
1.77Mpa |
|
Precision |
2.5 |
|
|
Working pressure |
1.61Mpa |
Safety Valve |
Model |
A42F-2.5-80 |
|
|
Designing temperature |
-19~50°C |
|
Version |
Built-in |
|
|
Filling Medium |
Propane |
|
Normal pressure |
2.5 Mpa |
|
|
Corrosion margin |
1.0mm |
|
Normal diameter |
DN50 |
|
|
Volume |
40CBM(40000L) |
|
Opening pressure |
1.68-1.76 Mpa |
|
|
Heat treatment |
bulk |
|
Re-seating pressure |
≥80% of opening pressure |
|
|
Filling factor |
420-590kg/m3 |
Handling System |
Normal Diameter |
Feed pip |
DN50 |
|
Material |
Q345R |
|
|
Drain pip |
DN50 |
|
Hydraulic test pressure |
2.22 Mpa |
|
|
Admission port |
DN50 |
|
Gas tight test pressure |
1.77 Mpa |
|
|
Sewage outfall port |
DN50 |
|
Cylinder thickness |
11.82mm |
|
|
Vent nozzle port |
DN50 |
|
Head thickness |
11.80mm |
stand |
GB150-1998<steel pressure vessels> |
||
|
Service time |
15 years |
|
Safety regulation of pressure vessels |
||
Accessory |
Safety valve, magnetic flap liquid level gauge, pressure gauge, thermometer, cut-off valves, etc. |
|||||
Specification |
Designed Pressure: 1.66Mpa Filling Ratio: 0.42 kg/L Working Temperature:-50℃ Corrosion Allowance: 1mm |
More pictures of hot sale skid lpg gas filling plant as below.
16metric tons mobile lpg gas cylinder refilling station for sale
best price skid lpg gas refilling station for sale
