Total new FOTON Aumark 12m3 electronic discharging feed truck for sale, hot sale livestock farm-oriented animal feed pellet transported truck
With the development of the livestock husbandry, the bulk feeds trucks become more and more important. Some small feedstuff factory actually don’t need large tonnage feed pellet truck. For this, Chengli Special Automobile Co., Ltd. designed and produced new small bulk feed transportation trucks for the small feeds factories, that is dongfeng 4ton bulk feed pellet truck-dongfeng furuika bulk grain carrier. This model of powder feed transportation tank truck is with the volume of 8cbm, adopts dongfeng furuika original chassis, high quality and competitive price, easy operation and maintenance, etc.
The feed tank is installed on the truck chassis; there is one mouth for loading at the tank top. And the helical delivering discharging pipe (also called discharging auger) on the tank top can rotate and upraise freely with the upraise angle of 60 degree. When transporting, the helical pipe lay on the tank top; when discharging, upraise. Connected the discharging feed outlet with the top inlet of feed storage tank controlled by the operation device at the driver cab or the tank rear part.
At present, we can design and sell 4ton bulk feed truck, 6ton feed pellet truck, 8ton poultry feeds delivery truck, dongfeng Tianjin 10ton-11ton bulk grain truck. And the feed tank volumes of 8cbm, 12cbm, 16cbm, 20cbm, 22cbm,45 cbm bulk feed semitrailer, etc. And we can design the bulk feed truck/trailer upon request.
If you're interested in our poultry feed truck, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
main parameters of hot sale 2017s total new FOTON Aumark 12m3 5tons-7tons farm-oriented animal feed delivery truck manufactured by Chengli Special Automobile Co., Ltd. as below
| 2017s total new FOTON Aumark 12m3 feed truck |
| FOTON Aumark LHD 154hp bulk feed truck chassis |
| Chassis model |
BJ |
Fuel type |
Diesel |
| Axle nos. |
2 |
Emission standard |
Euro 3 |
| Tyre nos. |
6+1 |
Tyre specification |
7.50 tires |
| Gearbox |
6 speed gearbox |
Wheelbase |
3800 |
| Driver cab |
FOTON Aumark single row driver cab |
Power steering |
Yes |
| Air cut brake |
Yes |
Air conditioner |
Yes, original air conditioner |
| Operation system |
Electronic hydraulic control |
Electronic system |
24V |
| Mp3, radio |
Yes |
Clutch booster |
Yes |
| Engine |
ISF3.8s3154
Cummins 154hp diesel Euro Ⅲ engine
|
Engine displacement(ml) |
3760ml |
| 2016s total new dongfeng 12cbm bulk feed truck |
| Product name |
Bulk feed truck |
Overall dimension(L*W*H) |
7700x2500x3550 |
| Tank volume |
11-14m3 |
Compartments |
2 compartments with 2 different feeds |
| Discharging speed |
400-550KG/min |
Rated mass |
5990 (kg) |
| discharging rotation angle |
±180 degree |
Max speed |
90 (km/h) |
| Discharging max angle of elevation: |
60 degree |
horizontal feeding distance |
6.1m |
| Vertical feeding distance |
7.6m |
Discharging way |
380Volts electronic discharging or hydraulic discharging auger discharging is selective |
| Remark |
1, the tank material adopts high quality carbon steel,
2, The feed tank is with 2 compartments to load 2 kinds of feeds with separate discharging operation system.
3, Sealed transportation and reducing wastage, saving manpower and bag price, easy operation and maintenance.
4, Low centre of gravity, reliable loading and discharging, good appearance with high quality
|
More pictures of hot sale FOTON AUMARK bulk feed delivery trucks manufactured by Chengli Special Automobile Co., Ltd. as below.
FOTON AUMARK 12M3 feed truck for sale
best price 5tons-7tons FOTON Aumark famr-oriented feed truck for sale
