HOT SALE FOTON KANGRUI 20m3 hydraulic discharging animal feed truck, FOTON 4*2 10tons hydraulic farm-oriented feed truck
Bulk feed delivery truck is main used for delivering, loading and discharging of feed pellets of different feed factories, large-type poultry farms, and also for transporting some non-corrosive feed pellets, such as pellets from pharmaceutical factory and turnover of grain depots, etc. the feed trucks manufactured by Chengli Special Automobile Co., Ltd. can transporting various feed pellet with the different compartments, the dream transporting vehicles for poultry farms and feed factories. More information, please feel free to contact with Ms. Anita Deng.
If you're interested in our hydraulic discharging poultry feed truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
main parameters of HOT SALE FOTON KANGRUI hydraulic discharging animal feed truck as below
| Product |
FOTON Hydraulic livestock animal feed truck for sale |
Overall dimension(L*W*H)(mm): |
8995x2450x3600 |
| Chassis model |
BJ1163VKPHK-A |
Cargo body dimension(mm): |
× |
| Total mass(kg) |
15600 |
Approach/departure angle(° ) |
21/14 |
| Rated mass(kg) |
7000 |
Front/rear suspension(mm): |
1450/2545,1450/2195 |
| Curb mass(kg) |
8405 |
Max speed(km/h): |
85 |
| Axle load |
5600/10000 |
| Truck chassis main parameters |
| Chassis model |
BJ1163VKPHK-A |
Manufacturer |
FOTON COMPANY |
| Axle nos. |
2 |
Fuel type |
Diesel |
| Wheelbase(mm): |
5000,5350 |
Front tread(mm): |
1935 |
| Tires nos. |
6 |
Rear tread(mm): |
1800,1860 |
| Tire specification |
8.25-20,8.25R20,9.00-20,9.00R20 |
| Engine parameters |
|
| Engine model |
Manufacturer |
Displacement (ml) |
Power (kw) |
|
| YC6J180-42 IE6D190-e4ES ISF3.8s4R168 |
Yuchai engine
Lovol engine
Foton Cummins
|
6500
5990
3760
|
132
140
125
|
|
| Emission standard |
Euro 4/Euro 3 |
Fuel type |
Diesel |
main parameters of foton 20m3 hydraulic feed tank as below
| Feed tank volume |
20cbm |
Discharging speed |
500-600 kg/min |
| Full discharging time |
18mins |
Discharging max elevation |
70 degree |
| Horizontal delivering range |
6.5m |
Rotation angle of discharging |
180 degree |
| Vertical delivering range |
8.3m |
Compartments |
3 compartments loading 3 different kinds of feeds |
| Discharging way |
Hydraulic auger system discharging, 380Volts electronis auger discharging is selective. |
Remark: 1, for the density of the feeds is various, so the loading tonnage is also various. The tank volume is 20cbm.
when the feeds density is 0.55ton/cbm, 0.6ton/cbm, 0.7ton/cbm, the loading mass is 11ton, 12ton, 14ton.
2, the bulk feeds truck adopts the special bulk feeds truck chassis, widely for long distance transportation, large size feedstuff factories, etc.
3,Different feeds delivering type decides different speed. Please consider the real areas to choose electronic auger or hydraulic auger, etc.
4, producing time: 10 working days.
More pictures of hot sale FOTON brand 20m3 htydraulic livestock pig feed transported truck as below
FOTON Brand hydraulic animal feed delivery truck for sale
factory direct sale 10TONS hydraulic farm-oriented pig/fish/chick feed pellet truck
best price CLW brand livestock animal feed truck for sale
