Hot sale FOTON AUMARK 4*2 LHD road sweeping vehicle, factory direct sale best price FOTON brand street sweeper truck
The road sweeper trucks manufactured by Chengli Special Automobile Co., Ltd. are with 4 sets of sweeping brushes, Cummins auxiliary engine, Italian imported motor, Schneider Electric switches, Taiwan Solenoid valves, maintenance-free and self-disconnect type clutch, maintenance-free fan, stainless steel water tank, stainless steel wastes van, rear part LED arrow lamp, manual portable pump Emergency system, etc.
The rotation mechanism of the front sweeper arm adopts high-tech rear-resistant work spacer sleeve, without buttering, precise cold-bending seamless hydraulic oil pipes, etc. If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Parameter of foton aumark road sweeper truck as below
| Vehicle information list |
| Truck model |
BJ1069VEJD6-AS |
| Total mass |
6495 |
Cabin seat |
2 |
|
| Rated mass |
2045 |
Vehicle size |
5780×2010×2450 |
|
| Curb weight |
4320 |
Suction volume |
3.5m3 |
|
| A/D angle |
22/28 |
F/R hang |
1085/1335 |
|
| Axles |
2 |
Wheel base |
3360 |
|
| Axles loading |
2335/4160 |
Max speed |
95 |
|
| Chassis information list |
| Chassis model |
BJ1069VEJD6-AS |
| Tyre |
6 |
Tyre specification |
6.00-15 |
|
| Leaf spring quantity |
7/4+5 |
Front track |
1530,1730 |
|
| Fuel type |
Diesel |
Rear track |
1425,1485,1590 |
|
| Engine model |
BJ493ZLQ3
95HP
|
Displacement/power |
2771ml/68kw |
|
| Special equipment |
Auxiliary engine models |
JX493G |
|
| Auxiliary engine power |
57 KW 77.5Horsepower |
|
| Cleaning width |
≥3-3.3 m |
|
| Water tanker volume |
1 m3 |
|
| Garbage box volume |
4 m3 |
|
| Working speed |
3~15 km/h |
|
| Max working capacity |
50000 m2/h |
|
| Maximum grain size and quality |
100 mm±1.5kg |
|
| Cleaning rate |
≥96% |
|
| Auxiliary engine models |
JX493G |
|
| |
|
|
|
|
|
More pictures of hot sale FOTON AUMARK mini road sweeper truck as below
FOTON AUMARK road sweeper truck for sale
Compared with common road sweeper, this model has more functions:Road sweeping, road flushing, multi-angle slush flushing, separation zone cleaning, freeway guard rail flushing,spraying, moistening and dust containing, high pressure water gun for car cleaning/low flat flushing with strong water flow, road sprinkling and flower watering from both sides and so on.
1.The Vice-engine sweepers no. Fans and other work devices to take power through the chassis engine to drive.
2. Cleaning device with Automatic Collision Avoidance Obstacle protection and automatic reset function (by national patent)
3. “Mid four brush - rear nozzle” structure layout with sweeping wide, clean and efficient features, and facilitate the cleaning device and nozzle adjustment and maintenance.
4.Pneumatic conveying system with digestion and absorption of foreign advanced technology and efficient sweepers dedicated fans and can auto-leveling with the road the whole floating nozzle.
5.Sweeper combined with trochar disc, it can work excellently and can automotically choose work type according to waste condition on the ground and speed of the truck. ;
6.Trash and water tank large, continuous cleaning operation a long time.
7. Left, right front linkage scan can work independently or can choose to use the right front or left front sweep sweep to work independently.
8.Hydraulic system with superimposed solenoid hydraulic valve, highly integrated, reliable, easy maintenance;
9. Control switch installed in the driver focused interior, all electronic control can be found in cab ,Beautiful appearance designed via computer
