Place of Origin: | China |
Brand Name: | CLW |
Certification: | ASME, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 40 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Material: | High Quality Q345R Material Special For Lpg Gas Pressure Vessels |
hot sale 20tons lpg gas canister filling plant, best price 20,000kgs mobile skid lpg gas refilling station for sale
Chengli Special Automobile Co., Ltd. is a professional manufacturer and supplier of lpg gas pressure vessels in China, such as surface/underground lpg gas storage tank, lpg gas trailer, lpg gas truck, skid lpg gas filling plant, etc. We can Provide you LPG Storage Tank. Truck Mounted LPG Tank. LPG Tank Container. LPG Tank Semitrailer. Propane Bobtail Refilling Truck, LPG Delivery Tank Truck, LPG Gas Refilling Tank Truck,lpg cylinder filling plant,lpg cylinder filling station, etc.
The technical advantages of the CLW lpg gas pressure vessels manufactured by Chengli Automobile Co., Ltd. as below
1.Our biggest capacity of LPG tank truck is 35.5cbm;
2. Our biggest capacity of LPG trailer is 59.6cbm;
3. the LPG storage tank lpg cylinder filling station is from 5cbm to 120cbm, 200CBM.
If you're interested in our skid lpg gas station, please feel free to send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat./Mob.: +86 13329899995.
Main parameters of hot sale 20tons lpg gas cylinders filling plant as below
THE SPECIFICATION OF LPG CYLINDER FILLING PLANT | |||||
Tank | Product Name | lpg cylinder filling plant | Liquid Indictor | Model | UHZ-518C14 |
Overall size(mm) | 12040*2200*3018 | Version | Magnetic | ||
Net weight(Kg) | 9380 | Normal pressure | 2.5Mpa | ||
Vessel type | III | Scope of testing | 50-2300mm | ||
Designing pressure | 250PSIG | Precision | 2.5 | ||
Test pressure | 325PSIG | Safety Valve | Model | A42F-2.5-80 | |
Designing temperature | -19~50°C | Version | Built-in | ||
Filling Medium | Propane | Normal pressure | 2.5 Mpa | ||
Corrosion margin | 1.0mm | Normal diameter | DN50 | ||
Volume | 40M3 | Opening pressure | 1.68-1.76 Mpa | ||
Heat treatment | bulk | Re-seating pressure | ≥80% of opening pressure | ||
Filling factor | 420-590kg/m3 | Handling System | Feed pip | DN50 | |
Material | Q345R | Drain pip | DN50 | ||
Hydraulic test pressure | 7000kPa | Admission port | DN50 | ||
Gas tight test pressure | 1.77 Mpa | Sewage outfall port | DN50 | ||
Cylinder thickness | 12mm | Vent nozzle port | DN50 | ||
Head thickness | 14mm | stand | GB150-1998 | ||
Service time | 15 years | Safety regulation of pressure vessels | |||
Accessory | Safety valve, magnetic flap liquid level gauge, pressure gauge, thermometer, cut-off valves, etc. | ||||
Specification | Designed Pressure: 1.72Mpa | ||||
Filling Ratio: 0.42 kg/L | |||||
Working Temperature:-50℃ | |||||
Corrosion Allowance: 1mm |
skid lpg gas plant Volume:
5m3, 8m3, 10m3, 12m3, 15m3, 20m3, 25m3, 32m3, 40m3, 45m3, 50m3, 60m3, 65m3, 80m3, 100m3, 120m3, etc.
Tests: Termal treatment, X-Ray test, hydrapress measurement, welding line density test.
Lpg gas pump and anti-static motor ∨
Digital scales ∨
Gas nozzles with pump ∨
Backflow valves ∨
Stop valve ∨
Check valve ∨
Alarm ∨
Pipe safety valve ∨
unloading pipe ∨
Quakeproof Pipe ∨
Elbow ∨
Flange ∨
Metal gasket ∨
Bolt Glass 8.8 ∨
Base ∨
Sprinkling system ∨
Safety equipment ∨
More pictures of hot sale 20tons mobile skid mounted lpg gas refilling station as below.
Skid lpg gas plant for sale
mobile skid lpg gas refilling station for gas canister for sale
More information, please feel free to contact with Ms. Anita.
Whatsapp/wehcat: +86 13329899995
Skype: truck0011
QQ: 504873236
