China Best quality low price road cleaning and sweeper truck for school community street cleaning use, hot sale street sweeping vehicle
Special features and sweeper sweeper main technical characteristics:
1 sweeper engine-driven fan through the Deputy and other working device used to suction the main suction sweeping combination of the working principle of wet dust cleaning operations carried out on the road, electro-hydraulic control control, hydraulic tipping discharge;
2 sweeper Vice transmission between the engine and the fan has a unique set of automatic clutch device. The device can ensure the engine load, Deputy Vice-engine starting and shutdown automatically with the fan off, simplify operations, reduce the impact of the Vice-engine to improve the work of Deputy engine reliability and service life, while the engine unless the work of deputy speed display, there are records of cumulative operating time of the auto show, easy to use and maintenance;
3, sweeper cleaning device with Automatic Obstacle avoidance protection and automatic reset function (national patent). Sweeper after sweeping obstacles encountered automatic retraction plate, across the barrier automatically reset, the feature effectively cleaning device is easy to solve the problem of collision damage;
4, rotation speed sweeper can sweep clean conditions to adjust the various options of high, medium and low grades, to ensure that conditions in the various forms of pollution can have a good cleaning results, but also reduce operating costs accordingly. Chip-type injection molding convenient replacement sweeping brush, and sweep the brush steel mixing options;
5, sweeper "in the home four brush - rear nozzle" structure layout, the width of a large sweeping, cleaning, high efficiency, and facilitate the cleaning device and the nozzle of the adjustment and maintenance; due to the short front overhang structure , a large nozzle ground clearance, so when the vehicle transitions through good transport;
6, sweeper pneumatic conveying system using the digestion and absorption of foreign advanced technology and efficient sweeper dedicated fan and can follow all the road leveling floating nozzle, suction strong, uniform nozzle ground clearance, the road of common garbage, sediment , buoyant material such as small stones and can suction clean;
7, sweeping road vehicles under the exhaust fan outlet by way of pressure dust effect, secondary pollution;
8, sweeping road vehicles can be imported high quality electric pump;
9, sweeper full stainless steel liner in the trash and water tank, corrosion-resistant;
10, sweeping chassis carrying capacity, large volume of trash and water tank, continuous operation for a long time.
11, sweeping cars left, right front linkage scan or work independently to ensure the use of the selective use of the right front or left front sweep sweep to work independently, if the scan does not work right front, both the lane and reduce the width of the vehicle to improve the operating and the safety of vehicles, but also reduces the sweeping brush wear, enabling lower operating costs;
12, the sweeper a hand pump with a unique emergency system, to ensure that the engine stop state, the Deputy can be retractable working device, lifting the trash, easy maintenance; hydraulic system uses electromagnetic hydraulic valve stack, highly integrated, arranged in neat rows , reliable, easy maintenance;
13 Road Sweeper control switch installed in the cab concentrated, all electric control panel can be equipped with heating and air conditioning in the driving chamber.
If you're interested in our CLW brand road sweeping vehicle, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of dongfeng road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
hot sale best price CLW Brand road sweeping vehicle
main technical parameters of hot sale CLW Brand mini road sweeper truck as below
| Basic Information |
Outline size (L×W×H) mm |
4500× 1780 × 2180 |
| capacity (litre) |
2000-6000 |
Empty mass weight (Kg) |
3500 |
| Chassis Information |
Chassis model |
EQ1061TJ21D5 |
| Driving Directions |
left hand drive or RHD |
| Wheel base(mm) |
2600,2900,3300 |
Max speed(km/h) |
95 |
| Tire specification |
6.00-14,7.00-16 |
Approach/departure angle ( o ) |
20/16 |
| Front track base(mm) |
1586 |
Rear track base(mm) |
1530 |
| Traction system |
4×2 |
Transmission |
6-speed |
| Number of axle |
2 |
Electric system |
24v |
| Operation control system |
Steering wheel |
Allowable passengers in cab |
3 |
| Engine Information |
Engine Model |
CY4102BZQ |
| Power/displacement(KW/ML) |
88hp/ 3856cc |
| Engine Manufacture |
Foton Diesel Engine |
| Equipment |
The vehicle-specific set feature of sweeping, cleaning, watering in one, and the operation is simple. |
| Sweep width: 3000 mm, cleaning capacity: 40000-60000m2 / h, cleaning speed: 3-20km/h , Cleaning Efficiency: 90%; maximum inhalation size: 120mm; nozzle minimum ground clearance: 200mm |
| Sweeping vehicle with brush 4, cleaning stainless steel tanks, bellows |
| Equipped with operating system |
| road sweeper truck (DongFeng XBW) |
Product Description
Vice engine: JX493Q1
Equipment Max. Cleaning width(mm): 3000
Max. Cleaning Capacity(m2/h): 60000
Cleaning degree: 90%
Max. Cleaning speed(km/h): 20
Max. Tipping angle(° ): 45
Mix. Dumping height(mm): 800
Dustbin capacity: 4 L
Volume of the water tank(L): 1000
|
