best seller-dongfeng D9 Euro 4 180hp 10cbm garbage compactor truck for sale, high quality and competitive price Dongfeng D9 10m3 compression garbage truck for sale
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
Driver cab color: white color; wastes van color: white.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
main technical parameters of Dongfeng 10m3 compacted garbage truck as below
| Dongfeng D9 4*2 LHD 10m3 180hp diesel garbage compactor truck(CLW5165ZYSD5) |
| Total mass(kg) |
15955 |
Curb mass(kg) |
8900 |
| Rated mass(kg) |
6100 |
Chassis model |
EQ1165LJ9BDE |
| Driver cab person |
3 |
Max speed(km/h) |
90 |
| Approach/departure angle(°) |
19/13 |
Front/rear suspension(mm) |
1230/2510 |
| Overall dimension(L*W*H)(mm) |
7690X2495X3350 |
Cargo body dimension(mm) |
XX |
| Axle nos. |
2 |
Axle load(kg) |
5595/10400 |
| Tyre specifications |
9.00R20 |
Tyre nos. |
6 |
| Front tread(mm) |
1856 |
Rear tread(mm) |
1806 |
| Wheelbase(mm) |
3950 |
Springs |
8/10+7 |
| Emission standard |
GB17691-2005 Euro Ⅴ,GB3847-2005 |
Fuel type |
Diesel |
| Engine model |
Manufacturer |
Displacement(ml) |
Power (KW) |
| ISB180 50 |
Dongfeng Cummins |
5900 |
132 |
| Gearbox |
Dongfeng 6 speed gearbox, manual |
Driver cab |
Dongfeng D9 4*2 LHD luxurious driver cab with original air conditioner, electronic windows and doors, central locking, etc. |
| ABS |
YES |
Axle |
3.9tons front axle/8tons axle |
| 1 |
Product name |
Dongfeng D9 4*2 LHD 10m3 garbage compactor truck |
| 2 |
Truck chassis |
EQ |
| 3 |
Engine model |
ISB 180 50 |
| 4 |
Engine power/displacement |
132KW/5900cc |
| 5 |
Oil consumption |
27.8L/100km |
| 6 |
Max speed |
90kw/h |
| 7 |
mini turning diameter |
18m |
| 8 |
Max gradability |
25﹪ |
| 9 |
wheelbase |
3950(mm) |
| 10 |
Volume |
10m3 |
| 11 |
Fuel type |
Diesel |
| 12 |
Wastes hopper lifting angle |
≥45° |
| 13 |
Loading and discharging way |
Overturning hopper/wastes bins mechanism |
| 14 |
Compacting way |
Bi-directional compression, wastes compacting density≥0.8tons/m3 |
| 15 |
One working circle time for loading(s) |
≤22 |
| 16 |
One working circle time for discharging(s) |
≤30 |
| 17 |
Overall dimension(L*W*H) |
7690X2495X3350 |
| 18 |
Max compressing force |
≥150KN, |
| 19 |
max pushing force |
≥180KN |
More pictures of Dongfeng D9 10M3 garbage compactor truck as below
HOT SALE! Dongfeng D9 10m3 compression garbage truck
High quality and competitive price Dongfeng D9 180hp garbage compactor truck for sale
Factory customized dongfeng 10cbm compacted garbage truck for sale
The garbage compactor trucks manufactured by Chengli Special Automobile Co., Ltd. is also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.
The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.
The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.
