HOT SALE! Customized SHACMAN Brand 6*4 LHD 18CBM garbage compactor truck, 15T refuse garbage compactor truck for sale
HOT SALE! SHACMAN brand 6*4 LHD 18CBM garbage compactor truck, adopts SHACMAN X6 half top roof cabin, 4375+1350mm wheelbase, YC6A260-33 260hp Euro 3 diesel engine, 9JS119A 9 speed gearbox, 5tons front axle, 13tons+13tons double rear axle, ￠395diaphragm clutch, 11.00R20 rail tires*10+1, 9JS119A 9 speed gearbox, etc.
The volume of SHACMAN brand 6*4 LHD 18CBM compacted garbage truck is 18cbm,and with the wastes loading capacity of about 14-15tons. THe wastes van of CLW Brand compacted garbage truck adopts high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way: PLC control system; loading and discharging way: rear loading wastes bins mechanism; compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; one working circle time for loading and discharging ≤30s; max compressing force≥150KN; max passing force≥180KN.
If you're interested in our compacted garbage truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of SHACMAN brand 6*4 LHD 260hp diesel 18CBM compacted garbage truck as below.
main technical parameters of SHACMAN brand 18cbm rear loader garbage truck as below.
| 1 |
Product name |
SHACMAN brand 6*4 LHD 18m3 garbage compactor truck for sale
|
| 2 |
Truck chassis model |
Sx1250
|
| 3 |
Overall dimension(L*W*H) |
10230×2500,2530×3400,3450
|
| 4 |
Total mass(kgs) |
25000 |
| 5 |
Curb mass(kgs) |
14000 |
| 6 |
Driver cab person |
3 included the driver |
| 7 |
Volume |
18cbm |
| 8 |
Real loading capacity |
About 14tons-15tons |
| 9 |
Max speed |
85kw/h |
| 10 |
Wheelbase |
4375+1350MM |
| 11 |
Axle nos. |
3 |
| 12 |
Driver cab |
SHACMAN X6 half top roof cabin |
| 13 |
Approach/departure angle(°) |
23/14 |
| 14 |
Front/rear suspension (mm) |
1240/2320 |
| 15 |
Front/rear tread(mm) |
1485/2675 |
| 16 |
Tire specification |
11.00R20/18PR |
| 17 |
Spring |
9/10 |
| 18 |
Engine model |
YC6A260-33 |
| 19 |
Rated power |
191KW/260hp |
| 20 |
Displacement(ml) |
7255ml |
| 21 |
Fuel type |
Diesel |
| 22 |
Emission standard |
Euro 3 |
| 23 |
Gearbox |
9 speed gearbox, manual |
| 24 |
Front/rear axle |
5tons front axle, 13tons+13tons double rear axle |
| 25 |
Color |
Different color upon request |
| 26 |
Wastes van |
Solid arc-shape box body of strength beam and steel plate welded |
| 27 |
Wastes van material |
High quality China standard light duty steel |
| 28 |
Operation way |
PLC control way |
| 29 |
Loading and discharging way |
Rear overturning mechanism |
| 30 |
Compacted way |
Bi-directional compression |
| 31 |
Wastes compacting density |
≥0.8tons/m3 |
| 32 |
One working circle time for loading and discharging |
≤30s |
| 33 |
Max compressing force |
≥150KN |
| 34 |
Max passing force |
≥180KN |
Our CLW brand compactor garbage truck is constructed with 12# low alloy steeland 5mm, 4mm, 10mm steel.The body is fitted on the chassis by the truck beam.The body floor is fully sealed.All the sewage can go directly into the sewage tank,so as not to corrode the body and chassis .Moreover,it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
The waste compression truck usually compacts the waste using a hydraulically powered mechanism that employs a moving plate or shovel to scoop the waste out from the loading hopper and compress it against a moving wall. In most compactor designs, the plate has a pointed edge (hence giving it the industry standard name packer blade) which is designed to apply point pressure to the waste to break down bulky items in the hopper before being drawn into the main body of the truck.
There are three kinds of mechanism options available to the customer,barrel turnover mechanism,panel turnover mechanism and tipping mechanism.by the use of hydraulics,the barrel is locked during the overturning process,which is very safe and reliable.
Garbage trucks are widely used in sanitation, municipal, factory and mining enterprises, and residential areas where have a lot of garbage. Garbage trucks are classified into compressed garbage trucks, swing arm type, dump type, sealed type, docking type, hook type arm type, and pull arm type garbage truck. Garbage trucks can carry multiple compartments in one vehicle, which can effectively prevent secondary pollution during the loading and unloading process. The modified part is separable from the original car chassis, which is easy to maintain and maintain the mobility and driving performance of the original car. Customers who have special requirements for garbage trucks please contact with us at any time. We can produce the trucks according to your requirements.
