Factory sale goodprice SINO TRUK HOWO Mini dump tipper truck,
Dump truck control by hydraulic system , dump truck side plate and floor plate made by high quality reinforced carbon steel , dump tippers heavy duty chassis optional :Dongfeng , Foton , Shacman , JAC , Sinotruck etc ..
As customer's required , our factory Chengli special autmobile co.,ltd could custom trucks :
dump truck laoding weight from 2 ton to 60 ton
Dump truck drive mode :4x2 ,6x4 ,6x6 ,8x4 ,8x8
SINO TRUK HOWO dump truck adopts SINO TRUK HOWO 4*2 Left Hand Drive, 2800mm wheelbase, 4DW93-84 90ho diesel engine, 2tons front axle/3.5tons rear axle, 6.50R16 tires*6, 5 speed gearbox, etc.
And the overall dimension(L*W*H) of the SINO TRUK HOWO mini dump tipper is 5450,5300×2060×2750 (mm), and the tipper box body dimension(L*W*H): 3400,3250,3100×1900×800,600,500 (mm).
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/MOb.: +86 13329899995.
More pictures of SINO TRUK HOWO dump tipper truck as below
customized SINO TRUK HOWO 3tons dump tipper truck for sale
high quality and competitive price HOWO tipper truck
HOT SALE! mini dump tipper truck for sale
More information, pleasefeel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
Main technical parameters of SINO TRUK HOWO 4*2 LHD 3tons dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. as below
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
SINO TRUK HOWO 4*2 LHD light duty dump truck for sale |
| Drive Type |
4*2 LHD, RHD is selective |
| Total mass(kg) |
4290 |
| Fact Loading Capacity(kg) |
Above 5000kg |
| Curb Weight (kg) |
2600(Kg) |
| Rated mass(kg) |
1495(Kg) |
| Overall Dimensions L*W*H(mm) |
5450,5300×2060×2750 (mm) |
| Engine |
Engine Model |
4DW93-84 |
| Engine Brand |
Xichai |
| Fuel Type |
Diesel |
| Power |
90HP |
| Emission Standard |
Euro Ⅱ |
| Displacement(ml) |
2540ml |
| Chassis |
Chassis Brand |
SINO TRUK HOWO |
| Front/Rear Axle Load(KG) |
1560/2730 |
| Tire No. |
6 |
| Tire Specification |
6.50R16 |
| Wheelbase (mm) |
2800 |
| Axle No. |
2 |
| Gear Box |
5 speed forward with 1 reverse, manual |
| Brake |
Air brake/ oil braking |
| Steering Wheel |
Left Hand Drive with power-assisted, RHD is selective |
| Axle(kg) |
2ton front axle/3.5tons rear axle |
| Tipping system |
Box inner dimension(mm) |
3400,3250,3100×1900×800,600,500 (mm) |
| Box material |
Carbon steel(high strength cold rolled sheet) |
