HOT SALE! FOTON 110hp diesel 4.08m length 15000-20000 day old chicks transported truck, live baby poultry ducks vehicle for sale
HOT SALE! Foton aoling day old chicks transported truck, adopts FOTON AOLING 1880mm driver cab, 3360mm wheelbase, 7.00R16 rail tires, 5 speed gearbox, air cut braking,4J28TC3 110hp diesel Euro 5 engine, etc.
The overall dimension(L*W*H)of the FOTON AOLING SUYUN series day old chick truck is 5995*2020*3000(mm), and the chick box van dimension(L*W*H) is 4085*2100*2100 (mm).
The specification of the day old chick box van body as below
1, high quality FRP(Fiber Glass-Reinforced Plastics) for the interior and exterior layer of the insulation body van box; and the middle insulation material with 80mm thickness high-density PU Foam.
2, the door locks and door frame with stainless steel material; the covered edge with aluminum alloy material; the truck floor with anti-slip diamond aluminum plate.
3,3 sets of blind windows with sliding doors for the left and right van sides
4, 4 sets of electronic ventilator fans for the rear plate and 2 sets of electronic ventilator fans for front plate.
5, Top mounted sky window* 2 sets
6, two line of air duct installed on the floor air flow is selective
7, China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10 degree, adjusted at the driver cab)
Day old chick truck is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.
There are ventilation and heating system inside the farm poultry transported truck. There are several electronic ventilator fans (according to the length of the insulation van) on the top for ventilating, assuring offering enough oxygen for the baby young chicks/ducks/ gooses in the van. There are several windows (according to the length of the chick box body) for ventilating, heating, oxygen-offering.
And we can design and installed shelves in the van body.
The poultry transported truck is mounted on the truck chassis, choosing high quality, high strength FRP materials with high-tech Sandwich crafts working.
The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
If you're interested in our day old chicks transported truck, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of FOTON 110hp diesel Euro 5 15000 day old chicks transported vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! high quality and competitive price FOTON Aoling Suyun 110hp diesel day old chicks truck for sale
customized 15000-20000 day old chicks transported vehicle for sale
the specification of FOTON AOLING SUYUN 110hp Euro 5 engine diesel 4.08length day old chick transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name |
FOTON AOLING 4*2 LHD day old chick transported truck |
| Overall dimension(L*W*H)(mm) |
5995×2310×3250 |
Chick van box dimension(L*W*H)mm |
4085*2100*2100 (mm). |
| Drive type |
4*2 LHD |
Total mass |
4495 |
| Gearbox |
5 speed transmission, manual |
Tyre specification |
7.00R16 rail tyres *6+1 |
| Power steering |
Yes |
Exhaust braking |
Yes |
| oil-cut braking |
Yes |
Driver cab |
Foton aoling 1880mm driver cab |
| Engine |
4J28TC5 |
Emission standard |
Euro Ⅴ |
| Rater power |
81KW/110hp |
Displacement (ml) |
2771 |
Main technical parameters of day old chick van body
| Performance and consumption |
| Heating system |
Watering system |
Without, client choose to install |
| Cooling system |
One refrigerated reefer |
China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) |
| Ventilation system |
Air duct installed on the floor for hot air flow |
Without, client choose to install |
| Cold air duct installed on the double sides of the van body |
Two lines as the pictures show |
| Blind windows |
3 sets of blind windows with smaller doors for the left and right van sides (as the pictures show), Blind Windows: 3*2=6 |
| electronic ventilator fans |
1, 4 sets of electronic ventilator fans for the rear plate door; 2 sets of electronic ventilator fans for front plate Electronic fans: 4+2=6 |
| |
Sky-window |
Top mounted sky windows 2 sets,
Sky-window: 2
|
| Dimension |
| Chick van box body |
Length |
4150mm |
| Width |
1750mm |
| Height |
1750m |
| Refrigerated van box |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices;
Aluminum-patterned baseplate; |
