|Place of Origin:||China|
|Certification:||CCC, ISO 9001|
|Minimum Order Quantity:||1 unit|
|Packaging Details:||in bulk package, waxed|
|Delivery Time:||20 days|
|Payment Terms:||T/T, L/C|
|Color:||Different Color Upon Request, Free To Paint Company Logo||Truck Chassis:||China Made Dongfeng D9 180hp Diesel Truck Chassis|
|Price:||High Quality Fatory Direct Sale Price||Refrigerated Unit:||China Made/ USA CARRIER Or THERMO KING Refrigerated Unit|
HOT SALE! Dongfeng D9 6.8m length 40000-50000 day old chicks transported vehicle for sale, baby live poultry transported car for sale
Day old chick truck is also called baby chick truck, young chicks transported truck. There are several electronic ventilator fans on the top, and the left-right sides with several slidable windows to keep air ventilated. There is cooling reefer, adjusted the temperature freely, suitable for transporting farm poultry, etc.
It is mainly for professional transporting day old chicks, day old ducks, baby goose, flowers, seedlings, etc. a good tools to improve efficiency and reduce transporting cost.
The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of van truck in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply refrigerated truck, insualtion body van box, cargo van truck, baby chick transported truck, etc. And our CLW brand van truck have been exported to many countries all over the world. More information, please feel free to contact with Ms. Anita.
If you're interested in our day old chicks transported truck, please send email to firstname.lastname@example.org or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Dongfeng D9 day old chicks transported truck, adopts Dongfeng D9 one row and a half driver cab, 5200mm wheelbase, ISB180 50 Cummins 180hp diesel Euro Ⅴ engine, 3.9tons front axle/8tons rear axle, fastgear 8 speed gearbox, 9.00R20 rail tires, air cut braking, power steering, etc.
The technical parameters of upper part for dongfeng D9 as below
The cold van body dimension of Dongfeng D9 day old chicks transported carrier is 6800*2340*2470(mm). The interior and exterior of the van box body with fiber reinforced plastics(FRP), and the middle insulation layers of 80mm thickness PU foam. There are sliding windows and waterproof blind-windows. The air will be from the van body floor ventilation
Left and right sides of the van body are with 12 sets 40*40 Mesh Plates for the cold air from the reefer. There are several 320*320 electronic ventilator fans mounted on the truck top and the rear door plate. Folding Shelves are for the two sides van body. Both Two sides of the van body with 5 blind-windows; while top mounted sky-window. Three lines of ventilator Air Ducts mounted on the van floor. The reefer choose high quality China made engine-powered refrigerator( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab). The heating system is selective.
More pictures of dongfeng D9 6.8m length day old chicks transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
HOT SALE! Dongfeng D9 6.8m length day old chicks transported truck
The specification of Dongfeng D9 6.8m length day old chicks transported truck manufactured by Chengli Special Automobile Co., Ltd. as below.
|Product name||Dongfeng D9 4*2 LHD day old chick transported truck|
|Overall dimension(L*W*H)(mm)||9080×2500×3850||Chick van box dimension(L*W*H)mm||6800*2340*2470 (mm).|
|Drive type||4*2 LHD||Total mass||16000|
|Gearbox||Fastgear 8 speed transmission, manual||Tyre specification||9.00R20 rail tyres *6+1|
|Power steering||Yes||Exhaust braking||Yes|
|Air cut braking||Yes||Driver cab||Dongfeng D9 one row and a half driver cab|
|Engine||ISB180 50||Emission standard||Euro Ⅴ|
|Rater power||132KW/180hp||Displacement (ml)||5990|
Main technical parameters of day old chick van body
|Performance and consumption|
|Heating system||Watering system||Without, client choose to install|
|Cooling system||One refrigerated reefer||China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab)|
|Ventilation system||Air duct installed on the floor for air flow||three line as the pictures show|
|Cold air ducts on the two sides of the van body||three cold air ducts for the refrigerated reefer|
|Blind windows||5 sets of blind windows for the left and right van sides (as the pictures show); one bigger water-proof blind window at the front van plate.
Blind Windows: 5*2+1=11
|electronic ventilator fans||1, 4 sets of electronic ventilator fans with sliding doors for the rear plate door; 4 sets of electronic ventilator fans for the van top
Electronic fans: 4+4=8
|Sky-window||Top mounted sky windows*2 Sky-windows: 2*1=2|
|Sliding window||One sliding window at the front van plate(as the picture show)|
|Chick van box body||Length||6800mm|
|Refrigerated van box||Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices;
