Day old chick transported truck is also called baby chick truck, truck for transporting day old chick, a kind of special insulation van truck for transporting day old chickens and eggs, etc. It is suitable for large chick farms, etc.
The baby chick trucks manufactured by Chengli Special Automobile Co., Ltd. adopts high quality Fiberglass Reinforced Plastic (FRP) for exterior and interior layer, and the middle insulation layer with 80mm PU foam sheets.
And we can customized the day old chick trucks, installed with cooling system, heating system, Ventilation system, windows and fans, etc. More information, please feel free to contact with Ms. Anita. Please send email to truck0011@163.com or talk to Anita directly byWhatsapp/Wechat/Mob.: +86 13329899995.
There are ventilation and heating system inside the farm poultry transported truck. There are several electronic ventilator fans (according to the length of the insulation van) on the top for ventilating, assuring offering enough oxygen for the baby young chicks/ducks/ gooses in the van. There are several windows (according to the length of the chick box body) for ventilating, heating, oxygen-offering.
And we can design and installed shelves in the van body.
The poultry transported truck is mounted on the truck chassis, choosing high quality, high strength FRP materials with high-tech Sandwich crafts working.
The advantages of the day old ducks truck are rainproof, dustproof, theft-proof, environmental protection, high efficiency, ventilating, insulation, large loading capacity, etc.
More pictures of CLW brand mini LHD day old chicks transported truck for 20,000 as below.
Main parameters of dongfeng day old chick transported truck chassis
| Product name |
Dongfeng 4*2 RHD day old chick transported truck |
| Overall dimension(L*W*H)(mm) |
5995X2020X3000 |
Chick van box dimension(L*W*H)mm |
4100X1850X1800 (mm). |
| Drive type |
4*2 RHD |
Total mass |
6495 |
| Gearbox |
5 speed transmission, manual |
Tyre specification |
7.00R16 rail tyres *6+1 |
| Power steering |
Yes |
Exhaust braking |
Yes |
| Air-cut braking |
Yes |
Driver cab |
Dongfeng furuika single row driver cab with air conditioner |
| Engine |
CY4100Q |
Emission standard |
Euro 3 |
| Rater power |
66KW/90hp |
Displacement (ml) |
3707 |
Main technical parameters of day old chick van body
| Performance and consumption |
| Heating system |
Watering system |
Without, client choose to install |
| Cooling system |
One refrigerated reefer |
China made high quality vehicle-powered refrigerated reefer( the lowest temperature inside the cold room box up to -10℃, adjusted at the driver cab) |
| Ventilation system |
Air duct installed on the floor for air flow |
Two line as the pictures show |
| Cold air ducts on the two sides of the van body |
Two cold air ducts for the refrigerated reefer |
| Blind windows |
3 sets of blind windows for the left and right van sides (as the pictures show), 2 sets of blind windows for the front plate.
Blind Windows: 3*2+2=8
|
| electronic ventilator fans |
1, 2 sets of electronic ventilator fans with sliding doors for the rear plate door; 3 sets of electronic ventilator fans for the van top
Electronic fans: 2+3*2=8
|
| |
Sky-window |
Top mounted sky windows*2 Sky-windows: 2*1=2 |
| Dimension |
| Chick van box body |
Length |
4100mm |
| Width |
1850mm |
| Height |
1800m |
| Refrigerated van box |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices;
Aluminum-patterned baseplate;
|
