Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Truck Chassis: | Chinamade Yuejin LHD Diesel Truck Chassis |
---|---|---|---|
Price: | High Quality Factory Direct Sale Price |
HOT SALE! YUEJIN 4*2 LHD 130hp diesel dump tipper truck, Good price yuejin diesel stone and coal transported truck for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
YUEJIN brand dump tipper truck adopts YUEJIN brand X500 single row driver cab, 3850mm wheelbase, yunnei 130hp diesel Euro 3 engine, 5 speed gearbox, 7.50-16 nylon tires, power steering and air cut braking, 7tons rear axle, etc.
The overall dimension of YUEJIN brand dump tipper truck is 6870×2280×2510(mm), the dump tipper body dimension(L*W*H): 4500/4200×2100×600(mm).The loading capacity of the YUEJIN dump truck is 6tons-8tons.
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
More pictures of YUEJIN dump truck as below.
Main technical parameters of YUEJIN brand 4*2 LHD 6tons-8tons dump tipper truck manufactured by Chengli Special Automobile CO., Ltd. as below.
Items | Descriptions | Specifications and Types |
General | Truck Name | YUEJIN 4*2 LHD 6tons dump tipper truck for sale |
Drive Type | 4*2 LHD | |
Total mass(kg) | 9945 | |
Fact Loading Capacity(kg) | 7000kgs | |
Curb Weight (kg) | 4850 | |
Overall Dimensions L*W*H(mm) | 6870×2280×2510 | |
Engine | Engine Model | YUNNEI 130hp diesel |
Engine Brand | Yunnei | |
Fuel Type | Diesel | |
Power | 130hp | |
Emission Standard | Euro III | |
Displacement(ml) | 3707 | |
Engine Type | 4 cylinder Vertical, in-line, water-cooled, 4-stroke | |
Chassis | Chassis Brand | NJ |
Front/Rear Axle Load(KG) | 3779/6166 | |
Tire No. | 6 | |
Tire Specification | 7.50-16 | |
Wheelbase (mm) | 3800 | |
Axle No. | 2 | |
Gear Box | 5 speed forward with 1 reverse, manual | |
Brake | Air brake | |
Steering Wheel | Light Hand Drive with power-assisted, | |
Tipping system | Box inner dimension(mm) | 4500/4200×2100×600 |
Box material | Carbon steel, side sheet: 3mm thickness, bottom 4mm thickness | |
Hydraulic cylinder position | Double cylinders at the center of the truck bottom | |
Discharge type | Rear tipping |
