Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
HOT SALE! yuejin 130hp diesel 4tons dump truck for sale
YUEJIN brand dump truck, adopts YUEJIN H100 single row driver cab, 3300mm wheelbase, yunnei 130hp diesel Euro 3 engine, 5 speed manual gearbox, 7tons rear axle, 7.50-16 nylon tires, etc.
The overall dimension of YUEJIN brand dump truck is 5975×2095×2275(mm), and the dump tipper body dimension(L*W*H): 3800×1950×600,800(mm). The loading capacity of yuejin dump truck is 4tons.
If you're interested in our dump truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of YUEJIN brand 130hp diesel dump tipper truck as below.
Main technical parameters of YUEJIN 4*2 LHD 4tons DUMP TRUCK as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
Yuejin 4*2 LHD light duty dump tipper truck for sale |
| Drive Type |
4*2 LHD |
| Total mass(kg) |
4290 |
| Curb Weight (kg) |
2600 |
| Loading capacity |
3-5tons |
| Overall Dimensions L*W*H(mm) |
5975×2095×2275 |
| Engine |
Engine Model |
Yunnei 130hp |
| Engine Brand |
YUNNEI |
| Fuel Type |
Diesel |
| Power |
130hp |
| Emission Standard |
Euro 2/3 |
| Displacement(ml) |
2999 |
| Chassis |
Chassis Brand |
Yuejin |
| Front/Rear Axle Load(KG) |
1500/2790 |
| Tire No. |
6 |
| Tire Specification |
7.50-16 |
| Wheelbase (mm) |
3300 |
| Axle No. |
2 |
| Gear Box |
5 speed gearbox, manual |
| Brake |
Air cut brake |
| Steering Wheel |
Left Hand Drive with power-assisted, |
| Axle(kg) |
7tons rear axle |
| Driver cab |
Yuejin |
| Tipping system |
Box inner dimension(mm) |
3800×1950×600,800 |
| Box material |
High quality Carbon steel, 3mm thickness for side sheet and 4mm thickness for bottom sheet. |
| Tipping way |
Double hydraulic cylinders middle installed tipping |
| Open type |
Rear door open |
