    Product Details:

    Place of Origin: CLW5080TZJ6
    Brand Name: CLW
    Certification: CCC, ISO 9001
    Model Number: CLW5080TZJ6

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 unit
    Price: negotiable
    Packaging Details: in bulk package, waxed
    Delivery Time: 20 days
    Payment Terms: T/T, L/C
    Supply Ability: 20units/month
    Contact Now
    Detailed Product Description
    Color: Different Color Upon Request, Free To Paint Company Logo Truck Chassis: Chinamade Dongfeng LHD Diesel Truck Chassis
    Price: High Quality Factory Direct Sale Price Drilling Depth: 70-200m Deffirent Types

    70M-100M depth water-well drilling rig vehicle for sale, vehicle drilling rig vehicle-mounted oil well drilling rig for sale



    Drilling rig truck is also called Water Well Drilling Rig truck, truck mounted drilling rig, vehicle-mounted drilling rig, truck vehicle mounted Water Well Drilling Rig, truck mounted water well drilling rig machine, etc.



    Dongfeng furuika Drilling Rig vehicle adopts dongfeng furuika truck chassis, yunnei 150hp Euro Ⅵ diesel engine(client choose Euro Ⅲ/Euro Ⅳ/Euro Ⅴ diesel engine), 3800mm wheelbase, 245/70R19.5 tires *6+1, 6 speed gearbox, with power steering, air cut braking and original air conditioner, etc.

    The main upper parts of the truck mounted drilling rig: Reduction Gearbox, Gyrator, winch, gearbox, mud/slurry pump, PTO, derrick, tower frame, water tap, etc.



    Brand: Dongfeng

    Model: CLW5080TZJ6

    Drilling hole diameter: 200mm

    Drilling hole depth: 100m

    Drilling hole angle range: 90°

    Electronic motor power: 105KW

    Mass: 7800kgs

    Customized: yes



    If you're interested in our water well drilling rig vehicle, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.



    More pictures of Dongfeng 4*2 LHD diesel water well drilling rig vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.

    70M-100M depth water-well drilling rig vehicle for sale, vehicle drilling rig vehicle-mounted oil well drilling rig

    70M-100M depth water-well drilling rig vehicle for sale, vehicle drilling rig vehicle-mounted oil well drilling rig70M-100M depth water-well drilling rig vehicle for sale, vehicle drilling rig vehicle-mounted oil well drilling rig





    main parameters of Dongfeng 4*2 LHD diesel water well drilling rig vehicle manufactured by Chengli Special Automobile Co., Ltd. as below.

    Maximum drilling depth

    Drilling hole diameter:ψ200mm at 70m depth Drilling hole diameter:ψ150mm at 100m depth

    Drilling rod diameter

    mm

    Rotator speed

    R/min Inverse rotating / 57 96 169
    Reverse rotating / 38

    Maximum feed/ Pull-up force

    KN 30/50

    Feed schedule

    mm 450

    Hoisting force of single rope

    KN 13

    Max working pressure of the mud/slurry pump

    Mpa 2



    Max displacement of the mud/slurry pump

    1/min 450

    Max pressure of the hydraulic system

    Mpa 8

    Overall dimension(L*W*H)

    mm 9100*2370*3180

    Curb mass

    kg 7800

    Drilling truck is also called mobile drilling platform, which is composed of automobile chassis, drilling equipment, transfer device, hydraulic system, tower and other parts. It is mainly used for the construction of seismic blast holes; the general survey exploration of oil, natural gas and solid minerals; the construction of engineering geological surveys for urban construction, railway and hydropower departments; shallow hydrogeological surveys and water well drilling.


    Main features of Dongfeng water well Drilling Machine as below.

    Pressure and strong lifting, saving manpower and reducing labor intensity.

    The hoist is a planetary hoist, which is flexible, safe and reliable in operation.

    A reverse gear mechanism is added to the reduction box, and a handle can be manipulated to enable the gyrator to have three positions of forward rotation, stop, and reverse rotation, which makes it easy to unscrew and unload the active drill rod, save time and effort.

    The mud pump has strong self-priming ability and adjustable 10-level flow.

    The faucet is small in size, light in weight and reliable in sealing.

    The active drill pipe has good rigidity and self-heavy weight. It can be pressurized by its own weight when drilling, and the drilling efficiency is high.

    The lifting and landing derricks are operated hydraulically, which is convenient, safe and reliable.

    The whole vehicle is equipped with four-stage hydraulic outriggers, which can adjust the extension length of any leg at will to adapt to different working places.
