Refrigerated truck manufactured by Chengli Special Automobile Co., Ltd with the van of vacuum composition adhesive PU foam sheet insulation layer. And the van surface is just flat and clean, high strength, long life time. And the insulation condition can reach the National A standard. All the door frame and door trims use stainless steel, And the outer and inside materials of the van can be upon request. The insulation layer if the refrigerated truck can choose 50mm thickness, 80mm thickness, choosing meat hook, vent gutter, single side door or double doors.
If you're interested in our refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.:+86 13329899995.
More pictures of SINO TRUK HOWO 5tons refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
main technical parameters of SINO TRUK HOWO 5tons-6tons refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Items |
Descriptions |
Specifications and Types |
| General |
Truck Name |
New SINO TRUK HOWO refrigerated truck for sale |
| Drive Type |
4*2 LHD, |
| Real loading capacity (kg) |
6,000 |
| Seating person |
2-3 |
| GVW (kg) |
9990 |
| Curb Weight (kg) |
5300 |
| Overall Dimensions (L*W*H) (mm) |
6995×2350×3500 |
| Insulation van dimension(L*W*H)(mm) |
5050×2150×2050 |
| Cold room volume |
22CBM |
| Driver cab |
SINO TRUK HOWO 2020mm width single row driver cab |
| Engine |
Engine Model |
CY4102BZLQ |
| Engine Brand |
Dongfeng chaochai |
| Fuel Type |
Diesel |
| Max output (hp/rpm) |
120hp/88KW |
| Emission Standard |
Euro Ⅲ |
| Capacity (cc) |
3856 |
| Engine type |
4 cylinders, inter-cooling diesel engine |
| Chassis |
Chassis Brand |
SINO TRUK HOWO |
| Tire Specification |
8.25R16 |
| Wheelbase (mm) |
3800 |
| Axle No. |
2 |
| Front/Rear axle |
2.7ton front driving axle/7.2ton rear driving axle |
| Steering Wheel |
Left Hand Drive |
| Gear Box |
6 speed gearbox, manual |
| Brake |
Air brake |
| Air-conditioner |
No, it is selective |
| Power steering |
Yes |
| Box Side |
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer. |
| Box Floor |
Baseboard adopts aluminum alloy anti-skipping diamond board |
| Doors |
double rear doors |
| Reefer |
Dependent reefer |
Famous China-made vehicle-powered refrigerated reefer, the lowest temperature up to -15℃. |
Chengli Special Automobile Co., Ltd manufactures refrigerator trucks since 2004s in China. With so many years’ experience in manufacturing, we Chengli Special Automobile Co. Ltd could manufacture and sell vaccine delivery vehicle, meat hook refrigerated truck, fruit and vegetables refrigerated truck, milk food transport refrigerator truck, insulation van truck, van refrigerated truck, freezer minibus, small refrigerated truck, medium freezer van truck, big refrigerated truck, refrigerator semi-trailer, freezer refrigerated vehicles, dongfeng brand cold room truck, ISUZU brand refrigerated truck, FAW refrigerated truck, FOTON refrigerated truck, Chang’an freezer van truck, Yuejin refrigerated truck, JMC refrigerated truck, CMAC refrigerator truck, Aoling refrigerated truck, the smallest refrigerated truck, etc. More information, please feel free to contact with Ms. Anita
