Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng LHD Diesel Truck Chassis |
New manufactured 10tons-15tons stone and sand dump tipper truck for sale, Wholesale price coal delivery tipper truck for sale
One unit of dongfeng dump tipper truck of dongfeng 153 4*2 LHD 190hp diesel engine is finished customized for overseas clients. Look at the finished pictures of dongfeng 153 190hp diesel dump tipper truck for stone and sand transportation is as below.
HOT SALE! DONGFENG 4*2 6 wheels dump tipper truck for stone and sand transportation for sale
If you're interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of dongfeng 153 dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
Items | Descriptions | Specifications and Types |
General | Truck Name | Dongfeng 153 190hp diesel dump tipper truck for sale |
Drive Type | 4*2, LHD;RHD is selective | |
Loading capacity | About 10tons | |
Gross Vehicle Weight(kg) | 15900kgs | |
Curb Weight (kg) | 7780kgs | |
Rated weight(kgs) | 7925kgs | |
Overall Dimensions L*W*H(mm) | 7850×2500,2550×2850,3100,3360 | |
Engine | Engine Model | B190 33 |
Fuel Type | Diesel | |
Power | 140kw/190HP | |
Emission Standard | Euro Ⅲ | |
Displacement(ml) | 5900 | |
Engine Type | 6 cylinders in line,water cooling, turbocharged diesel engine,inter-cooling, electric control | |
Chassis | ChassisBrand | Dongfeng |
Front/Rear Axle Load(KG) | 5950/9950 | |
Tire No. | 6 | |
Tire Specification | 10.00R20 | |
Wheelbase (mm) | 4500 | |
Axle No. | 2 | |
Gear Box | 8 speed gearbox | |
Front/rear suspension(mm) | 1260/2090 | |
Front/rear tread(mm) | 1933/1865 | |
Leaf Spring No. | 8/- | |
Driver cab | Dongfeng 153 one row and a half driver cab | |
Tipping system | Box inner dimension(mm) | 5000/5400×2300×600/800 |
Box material | Carbon steel,side 3mm,bottom 4mm | |
Hydraulic cylinder no.(set) | 2 | |
Hydraulic cylinder position | At the center of the truck bottom | |
Discharge type | Rear tipping |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
