Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng LHD Diesel Truck Chassis | Hydraulic Cover: | Choose To Install High Quality Top Mounted Hydraulic Cover |
Factory sale best price dongfeng 3T-5T dump tipper truck for wastes transportation, dump garbage truck for sale
CLW brand 4*2 LHD dump truck, adopts single row reserved driver cab, chaochai 90hp diesel engine, 3300mm wheelbase, 5 speed transmission, 1058 front/rear bridge, 7.00R15 rail tires, etc.
And the overall dimension of the Dongfeng mini dump truck is 5850*2000*23800(mm), cargo body dimension is 3760*1880*600 adopting high quality GB carbon steel, etc. And client choose to install high quality hydraulic cover to avoid the second pollution.
More pictures of Dongfeng 4*2 LHD 3T-5T dump tipper truck manufactured by Chengli Special Automobile Co., Ltd. is as below.
High quality and best price dump truck for transported domestic wastes for sale
HOT SALE! 4tons dump garbage truck for sale
If you‘re interested in our dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of dongfeng 4*2 LHD 3T-5T dump garbage truck for domestic wastes collecting for sale
Items | Descriptions | Specifications and Types |
General | Truck Name | dongfeng brand 4*2 LHD 4tons dump tipper truck for sale |
Drive Type | 4*2 LHD | |
Total mass(kg) | 6010 | |
Fact Loading Capacity(kg) | 3000-5000kgs | |
Curb Weight (kg) | 3500 | |
Overall Dimensions L*W*H(mm) | 5850*2000*2380 | |
Engine | Engine Model | CY4100Q |
Engine Brand | Chaochai | |
Fuel Type | Diesel | |
Power | 60kw/82HP | |
Emission Standard | Euro III | |
Displacement(ml) | 3707 | |
Engine Type | 4 cylinder Vertical, in-line, water-cooled, 4-stroke | |
Chassis | Chassis Brand | Dongfeng EQ1060 |
Front/Rear Axle Load(KG) | 1700/2565 | |
Tire No. | 6 | |
Tire Specification | 7.00R16 | |
Wheelbase (mm) | 3300 | |
Axle No. | 2 | |
Gear Box | 5 speed forward with 1 reverse, manual | |
Brake | Air brake | |
Steering Wheel | Right Hand Drive with power-assisted, | |
Tipping system | Box inner dimension(mm) | 3760*1880*600 |
Box material | Carbon steel, side sheet: 3mm thickness, bottom 4mm thickness | |
Hydraulic cylinder position | Double cylinders at the center of the truck bottom | |
Discharge type | Rear tipping | |
Remark | Clients choose to install environmental protection hydraulically cover |
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck and tipper truck in China. With many years' development, Chengli Special Automobile Co., Ltd. could offer the dump tipper trucks as below.
Dump truck series:
Drive mode :4x2 4x4 6x2 6x4 6x6 8x4
Capacity :5ton - 40ton
Chassis brand : Dongfeng , Foton , Sino truk HOWO , Shacman , IVECO hongyan ,FAW,JAC,JMC etc.
