Place of Origin: | China |
Brand Name: | dongfeng |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Price: | High Quality Factory Direct Sale Price |
---|---|---|---|
Truck Chassis: | Chinamade Dongfeng LHD Diesel Off Road All Wheels Drive Truck Head |
Customized dongfeng 6*6 153 off road military cargo transported vehicle for sale, new manufactured cross-road transported carrier for sale
More pictures of Dongfeng 153 6*6 6 wheels drive off road military cargo truck is as below.
customized dongfeng 6*6 6 wheels drive off-road cargo transporter for sale
high quality and best price dongfeng off road cargo van truck for sale
Main technical parameters of dongfeng brand 153 6*6 LHD military cargo truck is as below
Basic technical condition | |
Model | Dongfeng EQ2102G 6*6 153 single row |
Engine | Dongfeng Cummins B190 33 |
Gearbox | Mechanical gear, six forward blocking |
Transfer case | Machinery, two gears |
Front bridge | 3.5tons |
Middle axle/rear axle | 3.5tons/3.5tons |
Cab | Dongfeng 153 flathead semi-surface glass |
Tyres | 12.5R20(6+1) |
Electrical appliance | 24V circuit system |
Other | Hydraulic clutch power, hydraulic steering power, exhaust braking |
Special configuration |
1, there are 2 guns at the driver cab, and the rear window has a protective net. 2,6*6 full wheels drive, patented design, designed for harsh road conditions, 3, optional front gear, traction is 44100N. |
BASIC PARAMETERS | ||
Size parameters | Overall dimension(L*W*H)(mm) | 7760*2470*2740 |
Cargo box dimension(L*W*H)(mm) | 4800*2294*900 | |
Wheelbase | 3475+1250 | |
Approach/departure angle(°) | 35/34 | |
Quality parameters | Follow weight(kg) | 6725 |
Load quality(kg) | 3500(off-road) | |
Total mass | 10435 | |
Performance parameters | Max power (KW) | 140 |
Displacement(ml) | 5900 | |
Max torque (n.m) | 640 | |
Max speed(km/h) | 90 | |
Max gradeability(%) | 60 | |
Mini ground clearance(mm) | 305 | |
Mini turning radius(m) | ≦9.4 | |
Max vertical crossing obstacle height(mm) | 340 | |
Max fording depth(mm) | 550 | |
100KM fuel consumption(L) | 26.5 | |
Brake distance (30km/h full load) m | ≦ | |
Fuel tanker capacity (L) | 160+60 |
