Place of Origin: | China |
Brand Name: | CLW |
Certification: | CCC, ISO 9001 |
Minimum Order Quantity: | 1 unit |
---|---|
Price: | negotiable |
Packaging Details: | in bulk package, waxed |
Delivery Time: | 20 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 20units/month |
Color: | Different Color Upon Request, Free To Paint Company Logo | Truck Chassis: | Chinamade Dongfeng 6*6 All Wheels Drive Off Road LHD Diesel Truck Chassis |
---|---|---|---|
Material: | High Quality Carbon Steel For Side Sheet And Bottom Sheet | Price: | High Quality Factory Direct Sale Price |
HOT SALE! Best price dongfeng 6*6 LHD 210hp diesel dump tipper vehicle with Tarpaulin Pole and Tarpaulin, new military off road 6*6 all wheels driving tipper truck for sale
More pictures of dongfeng 6*6 all wheels drive off road dump tipper truck with Tarpaulin Pole and Tarpaulin manufactured by Chengli Special Automobile Co., Ltd. is as below.
HOT SALE! CLW brand 6*6 dump truck 6*6 6 wheels drive DUMP TIPPER TRUCK
CLW brand 6*6 dump truck 6*6 6 wheels drive mineral speicial vehicle is modifided by dongfeng military carrier, the car is not only inherited the excellent off-road performance of the original military vehicle, but also changed the container to selfunloading It is suitable for loading and unloading of goods, suitable for logistics transportation, industrial and mining transportation, etc.
If you're interested in our 6*6 wheels drive off road minitary dump tipper truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: 0086 13329899995.
Main technical parameters of dongfeng brand 6*6 wheels drive off road mine-use dump tipper truck is as below
Basic technical condition | |
Model | Dongfeng 6*6 6 wheels drive off road dump truck for sale |
Engine | Dongfeng Dummins B210 33 |
Gearbox | A135 type, gear mechanical, five forward files, one reversing |
Transfer case | Machinery, two gears |
Drive bridge | Bridge shell type: with a half-axle sleeve stamping welding monolithic bridge shell, front bridge isometric universal joint type: three-pin |
Cab | Flat head all metal welding closed structure, with a torsional flip mechanism, the front of the seat, the intermediate seat and the assistant seat at the front of the cab. |
Tyres | 12.5R20(6+1)child off-road type |
Electrical appliance | 24V circuit system |
BASIC PARAMETERS | ||
Size parameters | Overall dimension(L*W*H)(mm) | 7760*2470*2740 |
Cargo box dimension(L*W*H)(mm) | 4200*2294*900 | |
Wheelbase | 3500+1250 | |
Approach/departure angle(°) | 35/34 | |
Quality parameters | Follow weight(kg) | 6725 |
Loading mass(kgs) | 3500 | |
Total mass | 10435 | |
Performance parameters | Max power (KW) | 140 |
Displacement(ml) | 5900 | |
Max torque (n.m) | 640 | |
Max speed(km/h) | 85 | |
Max grade-ability(%) | 60 | |
Mini ground clearance(mm) | 320 | |
Mini turning radius(m) | ≯8.3 | |
100KM fuel consumption(L) | 30 | |
Tanker capacity | 160+60 | |
Others | Tarpaulin Pole and Tarpaulin included |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck in China since 2004s. And we can offer dongfeng dump truck, HOWO dump truck, ISUZU tipper truck, FAW dump tipper, North Benz dump truck, tipper trailer, etc. 4*2 dump truck, 4*4 dump truck, 6*4 tipper truck, 8*4 dump truck, etc. More information, please feel free to contact with Ms. Anita Deng. The hot sale line is 0086 13329899995.
Dump truck is also called tipper, dump tipping vehicle, sand and stone transporting vehicle, etc. Dump truck is mainly used for transporting loose material (such as sand, gravel, or dirt) for construction. A typical dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front, allowing the material in the bed to be deposited dumped on the ground behind the truck at the site of delivery.
The dumper truck for sale adopts is consisted of dump truck chassis, tipping box. It is mainly used for transport sands, stone, gravels, etc. As a dump truck manufacturer, the dump truck we produce are 4x2 dump truck, 6x4 dump truck, 8x4 dump truck, foton dump truck, dongfeng dump truck, howo dump truck, jac dump truck, jmc dump truck, etc.
