Vacuum sewage tank truck is also called sewage suction truck, sewer vacuum tank, sludge tank truck, septic tank truck, etc. It mainly used for sucking, transporting, and discharging of sewers from septic tank and sludge from drains. Widely used by municipal environment and sanitation department and residential management. More information, please feel free to contact with Ms. Anita. The hot sale line is 0086 13329899995.
The sewage suction tank truck is also called sewage truck,vacuum pump sewage truck, sewer vacuum truck, sewer tanker truck,vacuum sewage suction truck, sewage suction tanker truck, etc. It mainly used for for suction,transportation and discharge of sewage fromt septic tanker and sludge from drains. Widely used by municipal environment and sanitation department and residential management.
As a professional sewage truck manufacturer in China, the sewage tanker truck capacity is from 3000 liter to 16000 liters.
The septic tanker truck is with self-suction and self-unloding function. The tank can be lifted by hydraulic cylinder 45 degree and the rear door of the tanker can be also be open by hydraulically. So the sewage can be discharged from the tanker completely. This is also convienient for you to maintenance and clean the tanker. Overfill system with music horn is equipped to prevent the vacuum pump damage from sewage water into vacuum pump when the tanker is full.
Super power of vacuum pump, seamless die casted sheel cover, designing for container with high ability of pressure-resistance,double hydraulic jack systrm, more strength than cesspit empiter.
The suction depth of our vacuum tanker is more than 7 meter and sewage truck capacity is from 10000L to 16000 liters sewage truck is with high quality large-capacity vacuum pump. It is high efficiency and manpower saved.
If you're interested in our vacuum tanker truck, please send email to truck0011@163.com; or talk to Anita by Whatsapp: 0086 13329899995.
More pictures of Dongfeng tianlong 6*4 LHD 14,000Liters vacuum tanker truck is as below.
Customized dongfeng tianlong 6*4 14cbm vacuum tanker truck for sale
good price sludge tanker truck for sale
main technical parameters is as below
|
Product name
|
CLW5250GXW3 vacuum tanker truck for sale |
Product brand
|
CLW
|
|
Total mass(kgs)
|
25000 |
Tanker volume(m3)
|
14 |
|
Rated mass
|
12870, |
Overall dimension(L*W*H)
|
9600*2500*3450 |
|
Curb mass
|
12500 |
Cargo box dimension
|
×× |
|
Axle nos.
|
3 |
Wheelbase
|
4350+1350, |
|
Chassis model
|
DFL1250A8 |
Chassis name
|
Second type cargo truck chassis
|
| - |
- |
Tires nos.
|
10 |
|
Fuel type
|
Diesel
|
Tire specification
|
11.00R20 |
|
Emission standard
|
Euro Ⅲ |
|
Engine model
|
Engine manufacturer
|
Displacement(ML)
|
Power(KW)
|
| C260 33 |
Dongfeng Cummins
|
8300
|
191
|
vehicle performance and features is as below
Chassis: Cummins 260 Euro 3 diesel engine, Dongfeng Tianlong driver cab with air conditioner, fastgear 9 speed manual gearbox, 7T front axle/10T rear axle, 300mm double layers beam, 11.00R20 rail tires*6+1, with power steering, air cut braking and manual windows and doors, etc.
the upper part of vacuum tanker is as below.
1, the sewage tanker volume: 14cbm, adopts high quality wugang steel plate, 8mm thickness tanker wall. There are several anti-wave sheets inside the tanker. Tanker top is designed with 500mm opening for overhauling and cleaning tanker easily.
2, the vacuum pump adopts Shangdong zibo haosai 2BE204 water-circulating pump(vertical suction distance: 9m).
3, installed anti-overflow valve; the vacuum tube is installed with stainless steel material filter (preventing impurities into the pump)
4, the sewage four-way valve position is with 100mm diameter vibration-proof pressure gauge, which to resist the vibration of the working conditioner and reduce the pulsation of medium pressure.
5, one 100mm sewage suction inlet, one 150mm sewage outlet, rear part is with 600mm sewage outlet can be hydraulically open with locking device.
6, the vacuum tanker can be hydraulically lifting and tipping for easily discharging.
