dongfeng 4ton refrigerated truck for fresh fruits and vegetables for sale, RHD dongfeng mini refrigerated truck for sale
Dongfeng Furuika small refrigerated truck, adopts 1730mm wide B07 driver cab, 3300mm wheelbase, Euro 3Chaochai 95ho EGR engine, 525 transmission, 2ton front bridge, 3.5ton rear bridge, 7.00-16 nylon tyre, air-cut brake, power steering, etc.
The insulation van dimension of the dongfeng 3ton refrigerated truck is 4000×1850×1800(mm), exterior and interior with glass steel sheets, and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure.
Dongfeng Furuika small refrigerated truck, adopts 1730mm wide B07 driver cab, 3300mm wheelbase, Euro 3Chaochai 95ho EGR engine, 525 transmission, 2ton front bridge, 3.5ton rear bridge, 7.00-16 nylon tyre, air-cut brake, power steering, etc.
The insulation van dimension of the dongfeng 3ton refrigerated truck is 4000×1850×1800(mm), exterior and interior with glass steel sheets, and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure.
If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of hot sale dongfeng chaochai 95hp refrigerated truck for fresh fruits and vegetables as below.
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp: +86 13329899995
Skype: truck0011
Wechat: 13329899995
QQ: 504873236
main parameters of dongfeng 4tons cold room trucks manufactured by Chengli Special Automobile Co., Ltd. as below.
|
Items
|
Descriptions
|
Specifications and Types
|
|
General
|
Truck Name
|
Dongfeng 4tons refrigerated truck (CLW5061XLC3)
|
|
Drive Type
|
4*2 LHD, RHD is choosable
|
|
Payload (kg)
|
2865,2800
|
|
Seating person
|
2-3
|
|
GVW (kg)
|
6495
|
|
Curb Weight (kg)
|
3500
|
|
Overall Dimensions (L*W*H) (mm)
|
5995X2020X3000
|
|
Insulation van dimension(L*W*H)(mm)
|
4000X1850X1800
|
|
Driver cab
|
Dongfeng furuika single row driver cab
|
|
Engine
|
Engine Model
|
CY4102-C3F
|
|
Engine Brand
|
Dongfeng chaochai
|
|
Fuel Type
|
Diesel
|
|
Max output (hp/rpm)
|
95hp/70KW
|
|
Emission Standard
|
Euro Ⅲ
|
|
Capacity (cc)
|
3856
|
|
Engine type
|
4 cylinders, inter-cooling diesel engine
|
|
Chassis
|
Chassis Brand
|
Dongfeng
|
|
Tire Specification
|
7.00-16
|
|
Wheelbase (mm)
|
3300
|
|
Axle No.
|
2
|
|
Front/Rear axle
|
2ton front driving axle/3.5ton rear driving axle
|
|
Steering Wheel
|
Left hand drive, RHD is ok
|
|
Gear Box
|
5 speed gearbox, manual
|
|
Brake
|
Air brake
|
|
Air-conditioner
|
No, can be installed
|
|
Cold Room
|
Box inner dimension(mm)
|
4000X1850X1800 (mm)
|
|
Box Side
|
Exterior and interior with FRP( fiber reinforced plastic), and the middle with 80mm PU slices with vacuum negative pressure one-formed casting as the insulation layer, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure.
|
|
Box Floor
|
Baseboard adopts aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard.
|
|
Doors
|
Frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc.
The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability.
Door edgings, door locks and accessories use stainless steel materials.
|
|
Cooking unit
|
Huatai brand F300 Preservation cooling unit
|
Huatai brand F300 Preservation cooling unit, the temperature can be adjusted from zero degree to 8 degree below zero, etc. And the cooling unit can be adjusted at the driver cab.
|
|
Remark
|
The refrigerated truck can choose to install meat hangers, vent-slots, etc. and side doors.
|
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of refrigerated truck, refrigerator truck, insulation body truck, reefer van truck, freezer van truck, etc. in China. With many years'experience in developing, Chengli Special Automobile Co., Ltd. could produce and supply high quality and competitive ISUZU refrigerated truck, dongfeng refrigerator truck, FAW freezer van truck, Foton reefer van truck, JAC insulation body truck, JMC refrigerated truck, refrigerated van semitrailer, etc. And the cooling units of the refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. can choose China faous brand or exported ones, and the temperature in the insulation body can be adjusted from -5 degree to -18 degree.
The interior and exterior of the insulation body can be chosen the popular glass steel material, or stainless steel, aluminum alloy material, and the insulation van with strengthen, etc. the middle is PU slices with vacuum negative pressure one-formed casting, and the thickness is 80mm, approved the related Ministry of Health of food grade requirements, etc. just like sandwich structure. The refrigerated van has the advantages of high strength; strong anti-corrosion and aging resistance, low heat-conducting property, non-pollution, non-easy destroy, etc. And the baseboard is aluminum alloy anti-skipping diamond board, which assuring the insulation ability and the compact resistance of the baseboard. There are aluminum alloy ventilation slots on the baseboard. The frame of standard rear double doors adopts the stainless steel structure frame with light mass and perfect corrosive resistance, etc. The door edgings frames are sealed with the imported high quality epdm rubber, making sure the van insulation stability. Door edgings, door locks and accessories use stainless steel materials.
